执行细节
首先设置了默认的languageDriver
org/mybatis/mybatis/3.5.11/mybatis-3.5.11-sources.jar!/org/apache/ibatis/session/Configuration.java:215
在configuration的构造方法里

1
languageRegistry.setDefaultDriverClass(XMLLanguageDriver.class);

而在
org.apache.ibatis.builder.xml.XMLStatementBuilder#parseStatementNode
中，创建了sqlSource，这里就会根据前面的 LanguageDriver 的实现选择对应的 sqlSource ，

1
SqlSource sqlSource = langDriver.createSqlSource(configuration, context, parameterTypeClass);

createSqlSource 就会调用

1
2
3
4
5
@Override
public SqlSource createSqlSource(Configuration configuration, XNode script, Class<?> parameterType) {
  XMLScriptBuilder builder = new XMLScriptBuilder(configuration, script, parameterType);
  return builder.parseScriptNode();
}

再往下的逻辑在 parseScriptNode 中，org.apache.ibatis.scripting.xmltags.XMLScriptBuilder#parseScriptNode

1
2
3
4
5
6
7
8
9
10
public SqlSource parseScriptNode() {
  MixedSqlNode rootSqlNode = parseDynamicTags(context);
  SqlSource sqlSource;
  if (isDynamic) {
    sqlSource = new DynamicSqlSource(configuration, rootSqlNode);
  } else {
    sqlSource = new RawSqlSource(configuration, rootSqlNode, parameterType);
  }
  return sqlSource;
}

首先要解析dynamicTag，调用了org.apache.ibatis.scripting.xmltags.XMLScriptBuilder#parseDynamicTags

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
protected MixedSqlNode parseDynamicTags(XNode node) {
    List<SqlNode> contents = new ArrayList<>();
    NodeList children = node.getNode().getChildNodes();
    for (int i = 0; i < children.getLength(); i++) {
      XNode child = node.newXNode(children.item(i));
      if (child.getNode().getNodeType() == Node.CDATA_SECTION_NODE || child.getNode().getNodeType() == Node.TEXT_NODE) {
        String data = child.getStringBody("");
        TextSqlNode textSqlNode = new TextSqlNode(data);
        // ---------> 主要是这边的逻辑
        if (textSqlNode.isDynamic()) {
          contents.add(textSqlNode);
          isDynamic = true;
        } else {
          contents.add(new StaticTextSqlNode(data));
        }
      } else if (child.getNode().getNodeType() == Node.ELEMENT_NODE) { // issue #628
        String nodeName = child.getNode().getNodeName();
        NodeHandler handler = nodeHandlerMap.get(nodeName);
        if (handler == null) {
          throw new BuilderException("Unknown element <" + nodeName + "> in SQL statement.");
        }
        handler.handleNode(child, contents);
        isDynamic = true;
      }
    }
    return new MixedSqlNode(contents);
  }

判断是否是动态sql，调用了org.apache.ibatis.scripting.xmltags.TextSqlNode#isDynamic

1
2
3
4
5
6
7
public boolean isDynamic() {
  DynamicCheckerTokenParser checker = new DynamicCheckerTokenParser();
  // ----------> 主要是这里的方法
  GenericTokenParser parser = createParser(checker);
  parser.parse(text);
  return checker.isDynamic();
}

创建parser的时候可以看到这个parser是干了啥，其实就是找有没有${ , }

1
2
3
private GenericTokenParser createParser(TokenHandler handler) {
  return new GenericTokenParser("${", "}", handler);
}

如果是的话，就在上面把 isDynamic 设置为true 如果是true 的话就创建 DynamicSqlSource

1
sqlSource = new DynamicSqlSource(configuration, rootSqlNode);

如果不是的话就创建RawSqlSource

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
sqlSource = new RawSqlSource(configuration, rootSqlNode, parameterType);
```java

但是这不是一个真实可用的 `sqlSource` ，
实际创建的时候会走到这
```java
public RawSqlSource(Configuration configuration, SqlNode rootSqlNode, Class<?> parameterType) {
    this(configuration, getSql(configuration, rootSqlNode), parameterType);
  }

  public RawSqlSource(Configuration configuration, String sql, Class<?> parameterType) {
    SqlSourceBuilder sqlSourceParser = new SqlSourceBuilder(configuration);
    Class<?> clazz = parameterType == null ? Object.class : parameterType;
    sqlSource = sqlSourceParser.parse(sql, clazz, new HashMap<>());
  }

具体的sqlSource是通过org.apache.ibatis.builder.SqlSourceBuilder#parse 创建的
具体的代码逻辑是

1
2
3
4
5
6
7
8
9
10
11
public SqlSource parse(String originalSql, Class<?> parameterType, Map<String, Object> additionalParameters) {
  ParameterMappingTokenHandler handler = new ParameterMappingTokenHandler(configuration, parameterType, additionalParameters);
  GenericTokenParser parser = new GenericTokenParser("#{", "}", handler);
  String sql;
  if (configuration.isShrinkWhitespacesInSql()) {
    sql = parser.parse(removeExtraWhitespaces(originalSql));
  } else {
    sql = parser.parse(originalSql);
  }
  return new StaticSqlSource(configuration, sql, handler.getParameterMappings());
}

这里创建的其实是StaticSqlSource ,多带一句前面的parser是将原来这样select * from student where id = #{id} 的 sql 解析成了select * from student where id = ? 然后创建了StaticSqlSource

1
2
3
4
5
public StaticSqlSource(Configuration configuration, String sql, List<ParameterMapping> parameterMappings) {
  this.sql = sql;
  this.parameterMappings = parameterMappings;
  this.configuration = configuration;
}

为什么前面要讲这么多好像没什么关系的代码呢，其实在最开始我们执行sql的代码中

1
2
3
4
5
6
@Override
  public <E> List<E> query(MappedStatement ms, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler) throws SQLException {
    BoundSql boundSql = ms.getBoundSql(parameterObject);
    CacheKey key = createCacheKey(ms, parameterObject, rowBounds, boundSql);
    return query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
  }

这里获取了BoundSql，而BoundSql是怎么来的呢，首先调用了org.apache.ibatis.mapping.MappedStatement#getBoundSql

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
public BoundSql getBoundSql(Object parameterObject) {
    BoundSql boundSql = sqlSource.getBoundSql(parameterObject);
    List<ParameterMapping> parameterMappings = boundSql.getParameterMappings();
    if (parameterMappings == null || parameterMappings.isEmpty()) {
      boundSql = new BoundSql(configuration, boundSql.getSql(), parameterMap.getParameterMappings(), parameterObject);
    }

    // check for nested result maps in parameter mappings (issue #30)
    for (ParameterMapping pm : boundSql.getParameterMappings()) {
      String rmId = pm.getResultMapId();
      if (rmId != null) {
        ResultMap rm = configuration.getResultMap(rmId);
        if (rm != null) {
          hasNestedResultMaps |= rm.hasNestedResultMaps();
        }
      }
    }

    return boundSql;
  }

而我们从上面的解析中可以看到这里的sqlSource是一层RawSqlSource , 它的getBoundSql又是调用内部的sqlSource的方法

1
2
3
4
@Override
public BoundSql getBoundSql(Object parameterObject) {
  return sqlSource.getBoundSql(parameterObject);
}

内部的sqlSource 就是StaticSqlSource ，

1
2
3
4
@Override
public BoundSql getBoundSql(Object parameterObject) {
  return new BoundSql(configuration, sql, parameterMappings, parameterObject);
}

这个BoundSql的内容也比较简单

1
2
3
4
5
6
7
public BoundSql(Configuration configuration, String sql, List<ParameterMapping> parameterMappings, Object parameterObject) {
  this.sql = sql;
  this.parameterMappings = parameterMappings;
  this.parameterObject = parameterObject;
  this.additionalParameters = new HashMap<>();
  this.metaParameters = configuration.newMetaObject(additionalParameters);
}

而上次在这边org.apache.ibatis.executor.SimpleExecutor#doQuery 的时候落了个东西，就是StatementHandler的逻辑

1
2
3
4
5
6
7
8
9
10
11
12
@Override
public <E> List<E> doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
  Statement stmt = null;
  try {
    Configuration configuration = ms.getConfiguration();
    StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
    stmt = prepareStatement(handler, ms.getStatementLog());
    return handler.query(stmt, resultHandler);
  } finally {
    closeStatement(stmt);
  }
}

它是通过statementType来区分应该使用哪个statementHandler，我们这使用的就是PreparedStatementHandler

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
public RoutingStatementHandler(Executor executor, MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) {

  switch (ms.getStatementType()) {
    case STATEMENT:
      delegate = new SimpleStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
      break;
    case PREPARED:
      delegate = new PreparedStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
      break;
    case CALLABLE:
      delegate = new CallableStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
      break;
    default:
      throw new ExecutorException("Unknown statement type: " + ms.getStatementType());
  }

}

所以上次有个细节可以补充，这边的doQuery里面的handler.query 应该是调用了PreparedStatementHandler 的query方法

1
2
3
4
5
6
7
8
9
10
11
12
@Override
public <E> List<E> doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
  Statement stmt = null;
  try {
    Configuration configuration = ms.getConfiguration();
    StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
    stmt = prepareStatement(handler, ms.getStatementLog());
    return handler.query(stmt, resultHandler);
  } finally {
    closeStatement(stmt);
  }
}

因为上面prepareStatement中getConnection拿到connection是com.mysql.cj.jdbc.ConnectionImpl#ConnectionImpl(com.mysql.cj.conf.HostInfo)

1
2
3
4
5
6
@Override
public <E> List<E> query(Statement statement, ResultHandler resultHandler) throws SQLException {
  PreparedStatement ps = (PreparedStatement) statement;
  ps.execute();
  return resultSetHandler.handleResultSets(ps);
}

那又为什么是这个呢，可以在网上找，我们在mybatis-config.xml里配置的

1
<transactionManager type="JDBC"/>

因此在parseConfiguration中配置environment时

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
private void parseConfiguration(XNode root) {
    try {
      // issue #117 read properties first
      propertiesElement(root.evalNode("properties"));
      Properties settings = settingsAsProperties(root.evalNode("settings"));
      loadCustomVfs(settings);
      loadCustomLogImpl(settings);
      typeAliasesElement(root.evalNode("typeAliases"));
      pluginElement(root.evalNode("plugins"));
      objectFactoryElement(root.evalNode("objectFactory"));
      objectWrapperFactoryElement(root.evalNode("objectWrapperFactory"));
      reflectorFactoryElement(root.evalNode("reflectorFactory"));
      settingsElement(settings);
      // read it after objectFactory and objectWrapperFactory issue #631
      // ----------> 就是这里
      environmentsElement(root.evalNode("environments"));
      databaseIdProviderElement(root.evalNode("databaseIdProvider"));
      typeHandlerElement(root.evalNode("typeHandlers"));
      mapperElement(root.evalNode("mappers"));
    } catch (Exception e) {
      throw new BuilderException("Error parsing SQL Mapper Configuration. Cause: " + e, e);
    }
  }

调用的这个方法通过获取xml中的transactionManager 配置的类型，也就是JDBC

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
private void environmentsElement(XNode context) throws Exception {
  if (context != null) {
    if (environment == null) {
      environment = context.getStringAttribute("default");
    }
    for (XNode child : context.getChildren()) {
      String id = child.getStringAttribute("id");
      if (isSpecifiedEnvironment(id)) {
        // -------> 找到这里
        TransactionFactory txFactory = transactionManagerElement(child.evalNode("transactionManager"));
        DataSourceFactory dsFactory = dataSourceElement(child.evalNode("dataSource"));
        DataSource dataSource = dsFactory.getDataSource();
        Environment.Builder environmentBuilder = new Environment.Builder(id)
            .transactionFactory(txFactory)
            .dataSource(dataSource);
        configuration.setEnvironment(environmentBuilder.build());
        break;
      }
    }
  }
}

是通过以下方法获取的，

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
// 方法全限定名 org.apache.ibatis.builder.xml.XMLConfigBuilder#transactionManagerElement
private TransactionFactory transactionManagerElement(XNode context) throws Exception {
    if (context != null) {
      String type = context.getStringAttribute("type");
      Properties props = context.getChildrenAsProperties();
      TransactionFactory factory = (TransactionFactory) resolveClass(type).getDeclaredConstructor().newInstance();
      factory.setProperties(props);
      return factory;
    }
    throw new BuilderException("Environment declaration requires a TransactionFactory.");
  }

// 方法全限定名 org.apache.ibatis.builder.BaseBuilder#resolveClass
protected <T> Class<? extends T> resolveClass(String alias) {
    if (alias == null) {
      return null;
    }
    try {
      return resolveAlias(alias);
    } catch (Exception e) {
      throw new BuilderException("Error resolving class. Cause: " + e, e);
    }
  }

// 方法全限定名 org.apache.ibatis.builder.BaseBuilder#resolveAlias
  protected <T> Class<? extends T> resolveAlias(String alias) {
    return typeAliasRegistry.resolveAlias(alias);
  }
// 方法全限定名 org.apache.ibatis.type.TypeAliasRegistry#resolveAlias
  public <T> Class<T> resolveAlias(String string) {
    try {
      if (string == null) {
        return null;
      }
      // issue #748
      String key = string.toLowerCase(Locale.ENGLISH);
      Class<T> value;
      if (typeAliases.containsKey(key)) {
        value = (Class<T>) typeAliases.get(key);
      } else {
        value = (Class<T>) Resources.classForName(string);
      }
      return value;
    } catch (ClassNotFoundException e) {
      throw new TypeException("Could not resolve type alias '" + string + "'.  Cause: " + e, e);
    }
  }

而通过JDBC获取得是啥的，就是在Configuration的构造方法里写了的JdbcTransactionFactory

1
2
public Configuration() {
  typeAliasRegistry.registerAlias("JDBC", JdbcTransactionFactory.class);

所以我们在这

1
2
3
4
5
private SqlSession openSessionFromDataSource(ExecutorType execType, TransactionIsolationLevel level, boolean autoCommit) {
  Transaction tx = null;
  try {
    final Environment environment = configuration.getEnvironment();
    final TransactionFactory transactionFactory = getTransactionFactoryFromEnvironment(environment);

获得到的TransactionFactory 就是 JdbcTransactionFactory ，而后

1
2
3
4
5
6
7
8
9
tx = transactionFactory.newTransaction(environment.getDataSource(), level, autoCommit);
```java

创建的transaction就是JdbcTransaction
```java
  @Override
  public Transaction newTransaction(DataSource ds, TransactionIsolationLevel level, boolean autoCommit) {
    return new JdbcTransaction(ds, level, autoCommit, skipSetAutoCommitOnClose);
  }

然后我们再会上去看代码getConnection ,

1
2
3
4
5
6
7
8
9
protected Connection getConnection(Log statementLog) throws SQLException {
  // -------> 这里的transaction就是JdbcTransaction
  Connection connection = transaction.getConnection();
  if (statementLog.isDebugEnabled()) {
    return ConnectionLogger.newInstance(connection, statementLog, queryStack);
  } else {
    return connection;
  }
}

即调用了

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
  @Override
  public Connection getConnection() throws SQLException {
    if (connection == null) {
      openConnection();
    }
    return connection;
  }

  protected void openConnection() throws SQLException {
    if (log.isDebugEnabled()) {
      log.debug("Opening JDBC Connection");
    }
    connection = dataSource.getConnection();
    if (level != null) {
      connection.setTransactionIsolation(level.getLevel());
    }
    setDesiredAutoCommit(autoCommit);
  }
  @Override
  public Connection getConnection() throws SQLException {
    return popConnection(dataSource.getUsername(), dataSource.getPassword()).getProxyConnection();
  }

private PooledConnection popConnection(String username, String password) throws SQLException {
    boolean countedWait = false;
    PooledConnection conn = null;
    long t = System.currentTimeMillis();
    int localBadConnectionCount = 0;

    while (conn == null) {
      lock.lock();
      try {
        if (!state.idleConnections.isEmpty()) {
          // Pool has available connection
          conn = state.idleConnections.remove(0);
          if (log.isDebugEnabled()) {
            log.debug("Checked out connection " + conn.getRealHashCode() + " from pool.");
          }
        } else {
          // Pool does not have available connection
          if (state.activeConnections.size() < poolMaximumActiveConnections) {
            // Can create new connection
            // ------------> 走到这里会创建PooledConnection，但是里面会先调用dataSource.getConnection()
            conn = new PooledConnection(dataSource.getConnection(), this);
            if (log.isDebugEnabled()) {
              log.debug("Created connection " + conn.getRealHashCode() + ".");
            }
          } else {
            // Cannot create new connection
            PooledConnection oldestActiveConnection = state.activeConnections.get(0);
            long longestCheckoutTime = oldestActiveConnection.getCheckoutTime();
            if (longestCheckoutTime > poolMaximumCheckoutTime) {
              // Can claim overdue connection
              state.claimedOverdueConnectionCount++;
              state.accumulatedCheckoutTimeOfOverdueConnections += longestCheckoutTime;
              state.accumulatedCheckoutTime += longestCheckoutTime;
              state.activeConnections.remove(oldestActiveConnection);
              if (!oldestActiveConnection.getRealConnection().getAutoCommit()) {
                try {
                  oldestActiveConnection.getRealConnection().rollback();
                } catch (SQLException e) {
                  /*
                     Just log a message for debug and continue to execute the following
                     statement like nothing happened.
                     Wrap the bad connection with a new PooledConnection, this will help
                     to not interrupt current executing thread and give current thread a
                     chance to join the next competition for another valid/good database
                     connection. At the end of this loop, bad {@link @conn} will be set as null.
                   */
                  log.debug("Bad connection. Could not roll back");
                }
              }
              conn = new PooledConnection(oldestActiveConnection.getRealConnection(), this);
              conn.setCreatedTimestamp(oldestActiveConnection.getCreatedTimestamp());
              conn.setLastUsedTimestamp(oldestActiveConnection.getLastUsedTimestamp());
              oldestActiveConnection.invalidate();
              if (log.isDebugEnabled()) {
                log.debug("Claimed overdue connection " + conn.getRealHashCode() + ".");
              }
            } else {
              // Must wait
              try {
                if (!countedWait) {
                  state.hadToWaitCount++;
                  countedWait = true;
                }
                if (log.isDebugEnabled()) {
                  log.debug("Waiting as long as " + poolTimeToWait + " milliseconds for connection.");
                }
                long wt = System.currentTimeMillis();
                condition.await(poolTimeToWait, TimeUnit.MILLISECONDS);
                state.accumulatedWaitTime += System.currentTimeMillis() - wt;
              } catch (InterruptedException e) {
                // set interrupt flag
                Thread.currentThread().interrupt();
                break;
              }
            }
          }
        }
        if (conn != null) {
          // ping to server and check the connection is valid or not
          if (conn.isValid()) {
            if (!conn.getRealConnection().getAutoCommit()) {
              conn.getRealConnection().rollback();
            }
            conn.setConnectionTypeCode(assembleConnectionTypeCode(dataSource.getUrl(), username, password));
            conn.setCheckoutTimestamp(System.currentTimeMillis());
            conn.setLastUsedTimestamp(System.currentTimeMillis());
            state.activeConnections.add(conn);
            state.requestCount++;
            state.accumulatedRequestTime += System.currentTimeMillis() - t;
          } else {
            if (log.isDebugEnabled()) {
              log.debug("A bad connection (" + conn.getRealHashCode() + ") was returned from the pool, getting another connection.");
            }
            state.badConnectionCount++;
            localBadConnectionCount++;
            conn = null;
            if (localBadConnectionCount > (poolMaximumIdleConnections + poolMaximumLocalBadConnectionTolerance)) {
              if (log.isDebugEnabled()) {
                log.debug("PooledDataSource: Could not get a good connection to the database.");
              }
              throw new SQLException("PooledDataSource: Could not get a good connection to the database.");
            }
          }
        }
      } finally {
        lock.unlock();
      }

    }

    if (conn == null) {
      if (log.isDebugEnabled()) {
        log.debug("PooledDataSource: Unknown severe error condition.  The connection pool returned a null connection.");
      }
      throw new SQLException("PooledDataSource: Unknown severe error condition.  The connection pool returned a null connection.");
    }

    return conn;
  }

其实就是调用的

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
// org.apache.ibatis.datasource.unpooled.UnpooledDataSource#getConnection()
  @Override
  public Connection getConnection() throws SQLException {
    return doGetConnection(username, password);
  }
```java

然后就是
```java
private Connection doGetConnection(String username, String password) throws SQLException {
    Properties props = new Properties();
    if (driverProperties != null) {
      props.putAll(driverProperties);
    }
    if (username != null) {
      props.setProperty("user", username);
    }
    if (password != null) {
      props.setProperty("password", password);
    }
    return doGetConnection(props);
  }

继续这个逻辑

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
  private Connection doGetConnection(Properties properties) throws SQLException {
    initializeDriver();
    Connection connection = DriverManager.getConnection(url, properties);
    configureConnection(connection);
    return connection;
  }
    @CallerSensitive
    public static Connection getConnection(String url,
        java.util.Properties info) throws SQLException {

        return (getConnection(url, info, Reflection.getCallerClass()));
    }
private static Connection getConnection(
        String url, java.util.Properties info, Class<?> caller) throws SQLException {
        /*
         * When callerCl is null, we should check the application's
         * (which is invoking this class indirectly)
         * classloader, so that the JDBC driver class outside rt.jar
         * can be loaded from here.
         */
        ClassLoader callerCL = caller != null ? caller.getClassLoader() : null;
        synchronized(DriverManager.class) {
            // synchronize loading of the correct classloader.
            if (callerCL == null) {
                callerCL = Thread.currentThread().getContextClassLoader();
            }
        }

        if(url == null) {
            throw new SQLException("The url cannot be null", "08001");
        }

        println("DriverManager.getConnection(\"" + url + "\")");

        // Walk through the loaded registeredDrivers attempting to make a connection.
        // Remember the first exception that gets raised so we can reraise it.
        SQLException reason = null;

        for(DriverInfo aDriver : registeredDrivers) {
            // If the caller does not have permission to load the driver then
            // skip it.
            if(isDriverAllowed(aDriver.driver, callerCL)) {
                try {
                    // ----------> driver[className=com.mysql.cj.jdbc.Driver@64030b91]
                    println("    trying " + aDriver.driver.getClass().getName());
                    Connection con = aDriver.driver.connect(url, info);
                    if (con != null) {
                        // Success!
                        println("getConnection returning " + aDriver.driver.getClass().getName());
                        return (con);
                    }
                } catch (SQLException ex) {
                    if (reason == null) {
                        reason = ex;
                    }
                }

            } else {
                println("    skipping: " + aDriver.getClass().getName());
            }

        }

        // if we got here nobody could connect.
        if (reason != null)    {
            println("getConnection failed: " + reason);
            throw reason;
        }

        println("getConnection: no suitable driver found for "+ url);
        throw new SQLException("No suitable driver found for "+ url, "08001");
    }

上面的driver就是driver[className=com.mysql.cj.jdbc.Driver@64030b91]

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
// com.mysql.cj.jdbc.NonRegisteringDriver#connect
public Connection connect(String url, Properties info) throws SQLException {
        try {
            try {
                if (!ConnectionUrl.acceptsUrl(url)) {
                    return null;
                } else {
                    ConnectionUrl conStr = ConnectionUrl.getConnectionUrlInstance(url, info);
                    switch (conStr.getType()) {
                        case SINGLE_CONNECTION:
                            return ConnectionImpl.getInstance(conStr.getMainHost());
                        case FAILOVER_CONNECTION:
                        case FAILOVER_DNS_SRV_CONNECTION:
                            return FailoverConnectionProxy.createProxyInstance(conStr);
                        case LOADBALANCE_CONNECTION:
                        case LOADBALANCE_DNS_SRV_CONNECTION:
                            return LoadBalancedConnectionProxy.createProxyInstance(conStr);
                        case REPLICATION_CONNECTION:
                        case REPLICATION_DNS_SRV_CONNECTION:
                            return ReplicationConnectionProxy.createProxyInstance(conStr);
                        default:
                            return null;
                    }
                }
            } catch (UnsupportedConnectionStringException var5) {
                return null;
            } catch (CJException var6) {
                throw (UnableToConnectException)ExceptionFactory.createException(UnableToConnectException.class, Messages.getString("NonRegisteringDriver.17", new Object[]{var6.toString()}), var6);
            }
        } catch (CJException var7) {
            throw SQLExceptionsMapping.translateException(var7);
        }
    }

这是个 SINGLE_CONNECTION ,所以调用的就是 return ConnectionImpl.getInstance(conStr.getMainHost());
然后在这里设置了代理类

1
2
3
4
5
6
7
8
9
public PooledConnection(Connection connection, PooledDataSource dataSource) {
    this.hashCode = connection.hashCode();
    this.realConnection = connection;
    this.dataSource = dataSource;
    this.createdTimestamp = System.currentTimeMillis();
    this.lastUsedTimestamp = System.currentTimeMillis();
    this.valid = true;
    this.proxyConnection = (Connection) Proxy.newProxyInstance(Connection.class.getClassLoader(), IFACES, this);
  }

结合这个

1
2
3
4
@Override
public Connection getConnection() throws SQLException {
  return popConnection(dataSource.getUsername(), dataSource.getPassword()).getProxyConnection();
}

所以最终的connection就是com.mysql.cj.jdbc.ConnectionImpl@358ab600

发表于 分类于 ， 阅读次数： Disqus：

先补充两个点，
第一是前面我们说了
使用org.apache.ibatis.builder.xml.XMLConfigBuilder 创建了parser解析器，那么解析的结果是什么
看这个方法的返回值

1
2
3
4
5
6
7
8
public Configuration parse() {
  if (parsed) {
    throw new BuilderException("Each XMLConfigBuilder can only be used once.");
  }
  parsed = true;
  parseConfiguration(parser.evalNode("/configuration"));
  return configuration;
}

返回的是 org.apache.ibatis.session.Configuration , 而这个 Configuration 也是 mybatis 中特别重要的配置核心类，贴一下里面的成员变量，

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
public class Configuration {

  protected Environment environment;

  protected boolean safeRowBoundsEnabled;
  protected boolean safeResultHandlerEnabled = true;
  protected boolean mapUnderscoreToCamelCase;
  protected boolean aggressiveLazyLoading;
  protected boolean multipleResultSetsEnabled = true;
  protected boolean useGeneratedKeys;
  protected boolean useColumnLabel = true;
  protected boolean cacheEnabled = true;
  protected boolean callSettersOnNulls;
  protected boolean useActualParamName = true;
  protected boolean returnInstanceForEmptyRow;
  protected boolean shrinkWhitespacesInSql;
  protected boolean nullableOnForEach;
  protected boolean argNameBasedConstructorAutoMapping;

  protected String logPrefix;
  protected Class<? extends Log> logImpl;
  protected Class<? extends VFS> vfsImpl;
  protected Class<?> defaultSqlProviderType;
  protected LocalCacheScope localCacheScope = LocalCacheScope.SESSION;
  protected JdbcType jdbcTypeForNull = JdbcType.OTHER;
  protected Set<String> lazyLoadTriggerMethods = new HashSet<>(Arrays.asList("equals", "clone", "hashCode", "toString"));
  protected Integer defaultStatementTimeout;
  protected Integer defaultFetchSize;
  protected ResultSetType defaultResultSetType;
  protected ExecutorType defaultExecutorType = ExecutorType.SIMPLE;
  protected AutoMappingBehavior autoMappingBehavior = AutoMappingBehavior.PARTIAL;
  protected AutoMappingUnknownColumnBehavior autoMappingUnknownColumnBehavior = AutoMappingUnknownColumnBehavior.NONE;

  protected Properties variables = new Properties();
  protected ReflectorFactory reflectorFactory = new DefaultReflectorFactory();
  protected ObjectFactory objectFactory = new DefaultObjectFactory();
  protected ObjectWrapperFactory objectWrapperFactory = new DefaultObjectWrapperFactory();

  protected boolean lazyLoadingEnabled = false;
  protected ProxyFactory proxyFactory = new JavassistProxyFactory(); // #224 Using internal Javassist instead of OGNL

  protected String databaseId;
  /**
   * Configuration factory class.
   * Used to create Configuration for loading deserialized unread properties.
   *
   * @see <a href='https://github.com/mybatis/old-google-code-issues/issues/300'>Issue 300 (google code)</a>
   */
  protected Class<?> configurationFactory;

  protected final MapperRegistry mapperRegistry = new MapperRegistry(this);
  protected final InterceptorChain interceptorChain = new InterceptorChain();
  protected final TypeHandlerRegistry typeHandlerRegistry = new TypeHandlerRegistry(this);
  protected final TypeAliasRegistry typeAliasRegistry = new TypeAliasRegistry();
  protected final LanguageDriverRegistry languageRegistry = new LanguageDriverRegistry();

  protected final Map<String, MappedStatement> mappedStatements = new StrictMap<MappedStatement>("Mapped Statements collection")
      .conflictMessageProducer((savedValue, targetValue) ->
          ". please check " + savedValue.getResource() + " and " + targetValue.getResource());
  protected final Map<String, Cache> caches = new StrictMap<>("Caches collection");
  protected final Map<String, ResultMap> resultMaps = new StrictMap<>("Result Maps collection");
  protected final Map<String, ParameterMap> parameterMaps = new StrictMap<>("Parameter Maps collection");
  protected final Map<String, KeyGenerator> keyGenerators = new StrictMap<>("Key Generators collection");

  protected final Set<String> loadedResources = new HashSet<>();
  protected final Map<String, XNode> sqlFragments = new StrictMap<>("XML fragments parsed from previous mappers");

  protected final Collection<XMLStatementBuilder> incompleteStatements = new LinkedList<>();
  protected final Collection<CacheRefResolver> incompleteCacheRefs = new LinkedList<>();
  protected final Collection<ResultMapResolver> incompleteResultMaps = new LinkedList<>();
  protected final Collection<MethodResolver> incompleteMethods = new LinkedList<>();

这么多成员变量，先不一一解释作用，但是其中的几个参数我们应该是已经知道了的，第一个就是 mappedStatements ，上一篇我们知道被解析的mapper就是放在这里，后面的 resultMaps ，parameterMaps 也比较常用的就是我们参数和结果的映射map，这里跟我之前有一篇解释为啥我们一些变量的使用会比较特殊，比如list，可以参考这篇，keyGenerators是在我们需要定义主键生成器的时候使用。
然后第二点是我们创建的 org.apache.ibatis.session.SqlSessionFactory 是哪个，

1
2
3
public SqlSessionFactory build(Configuration config) {
  return new DefaultSqlSessionFactory(config);
}

是这个 DefaultSqlSessionFactory ，这是其中一个 SqlSessionFactory 的实现
接下来我们看看 openSession 里干了啥

1
2
3
public SqlSession openSession() {
  return openSessionFromDataSource(configuration.getDefaultExecutorType(), null, false);
}

这边有几个参数，第一个是默认的执行器类型，往上找找上面贴着的 Configuration 的成员变量里可以看到默认是
protected ExecutorType defaultExecutorType = ExecutorType.SIMPLE;

因为没有指明特殊的执行逻辑，所以默认我们也就用简单类型的，第二个参数是是事务级别，第三个是是否自动提交

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
private SqlSession openSessionFromDataSource(ExecutorType execType, TransactionIsolationLevel level, boolean autoCommit) {
  Transaction tx = null;
  try {
    final Environment environment = configuration.getEnvironment();
    final TransactionFactory transactionFactory = getTransactionFactoryFromEnvironment(environment);
    tx = transactionFactory.newTransaction(environment.getDataSource(), level, autoCommit);
    // --------> 先关注这里
    final Executor executor = configuration.newExecutor(tx, execType);
    return new DefaultSqlSession(configuration, executor, autoCommit);
  } catch (Exception e) {
    closeTransaction(tx); // may have fetched a connection so lets call close()
    throw ExceptionFactory.wrapException("Error opening session.  Cause: " + e, e);
  } finally {
    ErrorContext.instance().reset();
  }
}

具体是调用了 Configuration 的这个方法

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
public Executor newExecutor(Transaction transaction, ExecutorType executorType) {
  executorType = executorType == null ? defaultExecutorType : executorType;
  Executor executor;
  if (ExecutorType.BATCH == executorType) {
    executor = new BatchExecutor(this, transaction);
  } else if (ExecutorType.REUSE == executorType) {
    executor = new ReuseExecutor(this, transaction);
  } else {
    // ---------> 会走到这个分支
    executor = new SimpleExecutor(this, transaction);
  }
  if (cacheEnabled) {
    executor = new CachingExecutor(executor);
  }
  executor = (Executor) interceptorChain.pluginAll(executor);
  return executor;
}

上面传入的 executorType 是 Configuration 的默认类型，也就是 simple 类型，并且 cacheEnabled 在 Configuration 默认为 true，所以会包装成CachingExecutor ,然后后面就是插件了，这块我们先不展开
然后我们的openSession返回的就是创建了DefaultSqlSession

1
2
3
4
5
6
public DefaultSqlSession(Configuration configuration, Executor executor, boolean autoCommit) {
    this.configuration = configuration;
    this.executor = executor;
    this.dirty = false;
    this.autoCommit = autoCommit;
  }

然后就是调用 selectOne, 因为前面已经把这部分代码说过了，就直接跳转过来
org.apache.ibatis.session.defaults.DefaultSqlSession#selectList(java.lang.String, java.lang.Object, org.apache.ibatis.session.RowBounds, org.apache.ibatis.session.ResultHandler)

1
2
3
4
5
6
7
8
9
10
private <E> List<E> selectList(String statement, Object parameter, RowBounds rowBounds, ResultHandler handler) {
  try {
    MappedStatement ms = configuration.getMappedStatement(statement);
    return executor.query(ms, wrapCollection(parameter), rowBounds, handler);
  } catch (Exception e) {
    throw ExceptionFactory.wrapException("Error querying database.  Cause: " + e, e);
  } finally {
    ErrorContext.instance().reset();
  }
}

因为前面说了 executor 包装了 CachingExecutor ，所以会先调用

1
2
3
4
5
6
@Override
public <E> List<E> query(MappedStatement ms, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler) throws SQLException {
  BoundSql boundSql = ms.getBoundSql(parameterObject);
  CacheKey key = createCacheKey(ms, parameterObject, rowBounds, boundSql);
  return query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
}

然后是调用的真实的query方法

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
@Override
public <E> List<E> query(MappedStatement ms, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql)
    throws SQLException {
  Cache cache = ms.getCache();
  if (cache != null) {
    flushCacheIfRequired(ms);
    if (ms.isUseCache() && resultHandler == null) {
      ensureNoOutParams(ms, boundSql);
      @SuppressWarnings("unchecked")
      List<E> list = (List<E>) tcm.getObject(cache, key);
      if (list == null) {
        list = delegate.query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
        tcm.putObject(cache, key, list); // issue #578 and #116
      }
      return list;
    }
  }
  return delegate.query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
}

这里是第一次查询，没有缓存就先到最后一行，继续是调用到 org.apache.ibatis.executor.BaseExecutor#queryFromDatabase

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
@Override
  public <E> List<E> query(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql) throws SQLException {
    ErrorContext.instance().resource(ms.getResource()).activity("executing a query").object(ms.getId());
    if (closed) {
      throw new ExecutorException("Executor was closed.");
    }
    if (queryStack == 0 && ms.isFlushCacheRequired()) {
      clearLocalCache();
    }
    List<E> list;
    try {
      queryStack++;
      list = resultHandler == null ? (List<E>) localCache.getObject(key) : null;
      if (list != null) {
        handleLocallyCachedOutputParameters(ms, key, parameter, boundSql);
      } else {
        // ----------->会走到这里
        list = queryFromDatabase(ms, parameter, rowBounds, resultHandler, key, boundSql);
      }
    } finally {
      queryStack--;
    }
    if (queryStack == 0) {
      for (DeferredLoad deferredLoad : deferredLoads) {
        deferredLoad.load();
      }
      // issue #601
      deferredLoads.clear();
      if (configuration.getLocalCacheScope() == LocalCacheScope.STATEMENT) {
        // issue #482
        clearLocalCache();
      }
    }
    return list;
  }

然后是

1
2
3
4
5
6
7
8
9
10
11
12
13
14
private <E> List<E> queryFromDatabase(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, CacheKey key, BoundSql boundSql) throws SQLException {
  List<E> list;
  localCache.putObject(key, EXECUTION_PLACEHOLDER);
  try {
    list = doQuery(ms, parameter, rowBounds, resultHandler, boundSql);
  } finally {
    localCache.removeObject(key);
  }
  localCache.putObject(key, list);
  if (ms.getStatementType() == StatementType.CALLABLE) {
    localOutputParameterCache.putObject(key, parameter);
  }
  return list;
}

然后就是 simpleExecutor 的执行过程

1
2
3
4
5
6
7
8
9
10
11
12
@Override
public <E> List<E> doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
  Statement stmt = null;
  try {
    Configuration configuration = ms.getConfiguration();
    StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
    stmt = prepareStatement(handler, ms.getStatementLog());
    return handler.query(stmt, resultHandler);
  } finally {
    closeStatement(stmt);
  }
}

接下去其实就是跟jdbc交互了

1
2
3
4
5
6
@Override
public <E> List<E> query(Statement statement, ResultHandler resultHandler) throws SQLException {
  PreparedStatement ps = (PreparedStatement) statement;
  ps.execute();
  return resultSetHandler.handleResultSets(ps);
}

com.mysql.cj.jdbc.ClientPreparedStatement#execute

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
public boolean execute() throws SQLException {
        try {
            synchronized(this.checkClosed().getConnectionMutex()) {
                JdbcConnection locallyScopedConn = this.connection;
                if (!this.doPingInstead && !this.checkReadOnlySafeStatement()) {
                    throw SQLError.createSQLException(Messages.getString("PreparedStatement.20") + Messages.getString("PreparedStatement.21"), "S1009", this.exceptionInterceptor);
                } else {
                    ResultSetInternalMethods rs = null;
                    this.lastQueryIsOnDupKeyUpdate = false;
                    if (this.retrieveGeneratedKeys) {
                        this.lastQueryIsOnDupKeyUpdate = this.containsOnDuplicateKeyUpdate();
                    }

                    this.batchedGeneratedKeys = null;
                    this.resetCancelledState();
                    this.implicitlyCloseAllOpenResults();
                    this.clearWarnings();
                    if (this.doPingInstead) {
                        this.doPingInstead();
                        return true;
                    } else {
                        this.setupStreamingTimeout(locallyScopedConn);
                        Message sendPacket = ((PreparedQuery)this.query).fillSendPacket(((PreparedQuery)this.query).getQueryBindings());
                        String oldDb = null;
                        if (!locallyScopedConn.getDatabase().equals(this.getCurrentDatabase())) {
                            oldDb = locallyScopedConn.getDatabase();
                            locallyScopedConn.setDatabase(this.getCurrentDatabase());
                        }

                        CachedResultSetMetaData cachedMetadata = null;
                        boolean cacheResultSetMetadata = (Boolean)locallyScopedConn.getPropertySet().getBooleanProperty(PropertyKey.cacheResultSetMetadata).getValue();
                        if (cacheResultSetMetadata) {
                            cachedMetadata = locallyScopedConn.getCachedMetaData(((PreparedQuery)this.query).getOriginalSql());
                        }

                        locallyScopedConn.setSessionMaxRows(this.getQueryInfo().getFirstStmtChar() == 'S' ? this.maxRows : -1);
                        rs = this.executeInternal(this.maxRows, sendPacket, this.createStreamingResultSet(), this.getQueryInfo().getFirstStmtChar() == 'S', cachedMetadata, false);
                        if (cachedMetadata != null) {
                            locallyScopedConn.initializeResultsMetadataFromCache(((PreparedQuery)this.query).getOriginalSql(), cachedMetadata, rs);
                        } else if (rs.hasRows() && cacheResultSetMetadata) {
                            locallyScopedConn.initializeResultsMetadataFromCache(((PreparedQuery)this.query).getOriginalSql(), (CachedResultSetMetaData)null, rs);
                        }

                        if (this.retrieveGeneratedKeys) {
                            rs.setFirstCharOfQuery(this.getQueryInfo().getFirstStmtChar());
                        }

                        if (oldDb != null) {
                            locallyScopedConn.setDatabase(oldDb);
                        }

                        if (rs != null) {
                            this.lastInsertId = rs.getUpdateID();
                            this.results = rs;
                        }

                        return rs != null && rs.hasRows();
                    }
                }
            }
        } catch (CJException var11) {
            throw SQLExceptionsMapping.translateException(var11, this.getExceptionInterceptor());
        }
    }

发表于 更新于 分类于 ， 阅读次数： Disqus：

前一篇讲了mybatis的初始化使用，如果我第一次看到这个使用入门文档，比较会产生疑惑的是配置了mapper，怎么就能通过selectOne跟语句id就能执行sql了，那么第一个问题，就是mapper是怎么被解析的，存在哪里，怎么被拿出来的

添加解析mapper

1
2
3
4
org.apache.ibatis.session.SqlSessionFactoryBuilder#build(java.io.InputStream)
public SqlSessionFactory build(InputStream inputStream) {
  return build(inputStream, null, null);
}

通过读取mybatis-config.xml来构建SqlSessionFactory，

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
public SqlSessionFactory build(InputStream inputStream, String environment, Properties properties) {
  try {
    // 创建下xml的解析器
    XMLConfigBuilder parser = new XMLConfigBuilder(inputStream, environment, properties);
    // 进行解析，后再构建
    return build(parser.parse());
  } catch (Exception e) {
    throw ExceptionFactory.wrapException("Error building SqlSession.", e);
  } finally {
    ErrorContext.instance().reset();
    try {
       if (inputStream != null) {
         inputStream.close();
       }
    } catch (IOException e) {
      // Intentionally ignore. Prefer previous error.
    }
  }

创建XMLConfigBuilder

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
public XMLConfigBuilder(InputStream inputStream, String environment, Properties props) {
    // --------> 创建 XPathParser
  this(new XPathParser(inputStream, true, props, new XMLMapperEntityResolver()), environment, props);
}

public XPathParser(InputStream inputStream, boolean validation, Properties variables, EntityResolver entityResolver) {
    commonConstructor(validation, variables, entityResolver);
    this.document = createDocument(new InputSource(inputStream));
  }

private XMLConfigBuilder(XPathParser parser, String environment, Properties props) {
  super(new Configuration());
  ErrorContext.instance().resource("SQL Mapper Configuration");
  this.configuration.setVariables(props);
  this.parsed = false;
  this.environment = environment;
  this.parser = parser;
}

这里主要是创建了Builder包含了Parser
然后调用parse方法

1
2
3
4
5
6
7
8
9
10
public Configuration parse() {
  if (parsed) {
    throw new BuilderException("Each XMLConfigBuilder can only be used once.");
  }
  // 标记下是否已解析，但是这里是否有线程安全问题
  parsed = true;
  // --------> 解析配置
  parseConfiguration(parser.evalNode("/configuration"));
  return configuration;
}

实际的解析区分了各类标签

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
private void parseConfiguration(XNode root) {
  try {
    // issue #117 read properties first
    // 解析properties，这个不是spring自带的，需要额外配置，并且在config文件里应该放在最前
    propertiesElement(root.evalNode("properties"));
    Properties settings = settingsAsProperties(root.evalNode("settings"));
    loadCustomVfs(settings);
    loadCustomLogImpl(settings);
    typeAliasesElement(root.evalNode("typeAliases"));
    pluginElement(root.evalNode("plugins"));
    objectFactoryElement(root.evalNode("objectFactory"));
    objectWrapperFactoryElement(root.evalNode("objectWrapperFactory"));
    reflectorFactoryElement(root.evalNode("reflectorFactory"));
    settingsElement(settings);
    // read it after objectFactory and objectWrapperFactory issue #631
    environmentsElement(root.evalNode("environments"));
    databaseIdProviderElement(root.evalNode("databaseIdProvider"));
    typeHandlerElement(root.evalNode("typeHandlers"));
    // ----------> 我们需要关注的是mapper的处理
    mapperElement(root.evalNode("mappers"));
  } catch (Exception e) {
    throw new BuilderException("Error parsing SQL Mapper Configuration. Cause: " + e, e);
  }
}

然后就是调用到mapperElement方法了

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
private void mapperElement(XNode parent) throws Exception {
  if (parent != null) {
    for (XNode child : parent.getChildren()) {
      if ("package".equals(child.getName())) {
        String mapperPackage = child.getStringAttribute("name");
        configuration.addMappers(mapperPackage);
      } else {
        String resource = child.getStringAttribute("resource");
        String url = child.getStringAttribute("url");
        String mapperClass = child.getStringAttribute("class");
        if (resource != null && url == null && mapperClass == null) {
          ErrorContext.instance().resource(resource);
          try(InputStream inputStream = Resources.getResourceAsStream(resource)) {
            XMLMapperBuilder mapperParser = new XMLMapperBuilder(inputStream, configuration, resource, configuration.getSqlFragments());
            // --------> 我们这没有指定package，所以是走到这
            mapperParser.parse();
          }
        } else if (resource == null && url != null && mapperClass == null) {
          ErrorContext.instance().resource(url);
          try(InputStream inputStream = Resources.getUrlAsStream(url)){
            XMLMapperBuilder mapperParser = new XMLMapperBuilder(inputStream, configuration, url, configuration.getSqlFragments());
            mapperParser.parse();
          }
        } else if (resource == null && url == null && mapperClass != null) {
          Class<?> mapperInterface = Resources.classForName(mapperClass);
          configuration.addMapper(mapperInterface);
        } else {
          throw new BuilderException("A mapper element may only specify a url, resource or class, but not more than one.");
        }
      }
    }
  }
}

核心就在这个parse()方法

1
2
3
4
5
6
7
8
9
10
11
12
public void parse() {
  if (!configuration.isResourceLoaded(resource)) {
    // -------> 然后就是走到这里,配置xml的mapper节点的内容
    configurationElement(parser.evalNode("/mapper"));
    configuration.addLoadedResource(resource);
    bindMapperForNamespace();
  }

  parsePendingResultMaps();
  parsePendingCacheRefs();
  parsePendingStatements();
}

具体的处理逻辑

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
private void configurationElement(XNode context) {
  try {
    String namespace = context.getStringAttribute("namespace");
    if (namespace == null || namespace.isEmpty()) {
      throw new BuilderException("Mapper's namespace cannot be empty");
    }
    builderAssistant.setCurrentNamespace(namespace);
    cacheRefElement(context.evalNode("cache-ref"));
    cacheElement(context.evalNode("cache"));
    parameterMapElement(context.evalNodes("/mapper/parameterMap"));
    resultMapElements(context.evalNodes("/mapper/resultMap"));
    sqlElement(context.evalNodes("/mapper/sql"));
    // ------->  走到这，从上下文构建statement
    buildStatementFromContext(context.evalNodes("select|insert|update|delete"));
  } catch (Exception e) {
    throw new BuilderException("Error parsing Mapper XML. The XML location is '" + resource + "'. Cause: " + e, e);
  }
}

具体代码在这，从上下文构建statement，只不过区分了下databaseId

1
2
3
4
5
6
7
private void buildStatementFromContext(List<XNode> list) {
  if (configuration.getDatabaseId() != null) {
    buildStatementFromContext(list, configuration.getDatabaseId());
  }
  // -----> 判断databaseId
  buildStatementFromContext(list, null);
}

判断下databaseId

1
2
3
4
5
6
7
8
9
10
11
private void buildStatementFromContext(List<XNode> list, String requiredDatabaseId) {
  for (XNode context : list) {
    final XMLStatementBuilder statementParser = new XMLStatementBuilder(configuration, builderAssistant, context, requiredDatabaseId);
    try {
      // -------> 解析statement节点
      statementParser.parseStatementNode();
    } catch (IncompleteElementException e) {
      configuration.addIncompleteStatement(statementParser);
    }
  }
}

接下来就是真正处理的xml语句内容的，各个节点的信息内容

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
public void parseStatementNode() {
  String id = context.getStringAttribute("id");
  String databaseId = context.getStringAttribute("databaseId");

  if (!databaseIdMatchesCurrent(id, databaseId, this.requiredDatabaseId)) {
    return;
  }

  String nodeName = context.getNode().getNodeName();
  SqlCommandType sqlCommandType = SqlCommandType.valueOf(nodeName.toUpperCase(Locale.ENGLISH));
  boolean isSelect = sqlCommandType == SqlCommandType.SELECT;
  boolean flushCache = context.getBooleanAttribute("flushCache", !isSelect);
  boolean useCache = context.getBooleanAttribute("useCache", isSelect);
  boolean resultOrdered = context.getBooleanAttribute("resultOrdered", false);

  // Include Fragments before parsing
  XMLIncludeTransformer includeParser = new XMLIncludeTransformer(configuration, builderAssistant);
  includeParser.applyIncludes(context.getNode());

  String parameterType = context.getStringAttribute("parameterType");
  Class<?> parameterTypeClass = resolveClass(parameterType);

  String lang = context.getStringAttribute("lang");
  LanguageDriver langDriver = getLanguageDriver(lang);

  // Parse selectKey after includes and remove them.
  processSelectKeyNodes(id, parameterTypeClass, langDriver);

  // Parse the SQL (pre: <selectKey> and <include> were parsed and removed)
  KeyGenerator keyGenerator;
  String keyStatementId = id + SelectKeyGenerator.SELECT_KEY_SUFFIX;
  keyStatementId = builderAssistant.applyCurrentNamespace(keyStatementId, true);
  if (configuration.hasKeyGenerator(keyStatementId)) {
    keyGenerator = configuration.getKeyGenerator(keyStatementId);
  } else {
    keyGenerator = context.getBooleanAttribute("useGeneratedKeys",
        configuration.isUseGeneratedKeys() && SqlCommandType.INSERT.equals(sqlCommandType))
        ? Jdbc3KeyGenerator.INSTANCE : NoKeyGenerator.INSTANCE;
  }

  // 语句的主要参数解析
  SqlSource sqlSource = langDriver.createSqlSource(configuration, context, parameterTypeClass);
  StatementType statementType = StatementType.valueOf(context.getStringAttribute("statementType", StatementType.PREPARED.toString()));
  Integer fetchSize = context.getIntAttribute("fetchSize");
  Integer timeout = context.getIntAttribute("timeout");
  String parameterMap = context.getStringAttribute("parameterMap");
  String resultType = context.getStringAttribute("resultType");
  Class<?> resultTypeClass = resolveClass(resultType);
  String resultMap = context.getStringAttribute("resultMap");
  String resultSetType = context.getStringAttribute("resultSetType");
  ResultSetType resultSetTypeEnum = resolveResultSetType(resultSetType);
  if (resultSetTypeEnum == null) {
    resultSetTypeEnum = configuration.getDefaultResultSetType();
  }
  String keyProperty = context.getStringAttribute("keyProperty");
  String keyColumn = context.getStringAttribute("keyColumn");
  String resultSets = context.getStringAttribute("resultSets");

  // --------> 添加映射的statement
  builderAssistant.addMappedStatement(id, sqlSource, statementType, sqlCommandType,
      fetchSize, timeout, parameterMap, parameterTypeClass, resultMap, resultTypeClass,
      resultSetTypeEnum, flushCache, useCache, resultOrdered,
      keyGenerator, keyProperty, keyColumn, databaseId, langDriver, resultSets);
}

添加的逻辑具体可以看下

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
public MappedStatement addMappedStatement(
    String id,
    SqlSource sqlSource,
    StatementType statementType,
    SqlCommandType sqlCommandType,
    Integer fetchSize,
    Integer timeout,
    String parameterMap,
    Class<?> parameterType,
    String resultMap,
    Class<?> resultType,
    ResultSetType resultSetType,
    boolean flushCache,
    boolean useCache,
    boolean resultOrdered,
    KeyGenerator keyGenerator,
    String keyProperty,
    String keyColumn,
    String databaseId,
    LanguageDriver lang,
    String resultSets) {

  if (unresolvedCacheRef) {
    throw new IncompleteElementException("Cache-ref not yet resolved");
  }

  id = applyCurrentNamespace(id, false);
  boolean isSelect = sqlCommandType == SqlCommandType.SELECT;

  MappedStatement.Builder statementBuilder = new MappedStatement.Builder(configuration, id, sqlSource, sqlCommandType)
      .resource(resource)
      .fetchSize(fetchSize)
      .timeout(timeout)
      .statementType(statementType)
      .keyGenerator(keyGenerator)
      .keyProperty(keyProperty)
      .keyColumn(keyColumn)
      .databaseId(databaseId)
      .lang(lang)
      .resultOrdered(resultOrdered)
      .resultSets(resultSets)
      .resultMaps(getStatementResultMaps(resultMap, resultType, id))
      .resultSetType(resultSetType)
      .flushCacheRequired(valueOrDefault(flushCache, !isSelect))
      .useCache(valueOrDefault(useCache, isSelect))
      .cache(currentCache);

  ParameterMap statementParameterMap = getStatementParameterMap(parameterMap, parameterType, id);
  if (statementParameterMap != null) {
    statementBuilder.parameterMap(statementParameterMap);
  }

  MappedStatement statement = statementBuilder.build();
  // ------>  正好是这里在configuration中添加了映射好的statement
  configuration.addMappedStatement(statement);
  return statement;
}

而里面就是往map里添加

1
2
3
public void addMappedStatement(MappedStatement ms) {
  mappedStatements.put(ms.getId(), ms);
}

获取mapper

1
StudentDO studentDO = session.selectOne("com.nicksxs.mybatisdemo.StudentMapper.selectStudent", 1);

就是调用了 org.apache.ibatis.session.defaults.DefaultSqlSession#selectOne(java.lang.String, java.lang.Object)

1
2
3
4
5
6
7
8
9
10
11
public <T> T selectOne(String statement, Object parameter) {
  // Popular vote was to return null on 0 results and throw exception on too many.
  List<T> list = this.selectList(statement, parameter);
  if (list.size() == 1) {
    return list.get(0);
  } else if (list.size() > 1) {
    throw new TooManyResultsException("Expected one result (or null) to be returned by selectOne(), but found: " + list.size());
  } else {
    return null;
  }
}

调用实际的实现方法

1
2
3
public <E> List<E> selectList(String statement, Object parameter) {
  return this.selectList(statement, parameter, RowBounds.DEFAULT);
}

这里还有一层

1
2
3
public <E> List<E> selectList(String statement, Object parameter, RowBounds rowBounds) {
  return selectList(statement, parameter, rowBounds, Executor.NO_RESULT_HANDLER);
}

根本的就是从configuration里获取了mappedStatement

1
2
3
4
5
6
7
8
9
10
11
private <E> List<E> selectList(String statement, Object parameter, RowBounds rowBounds, ResultHandler handler) {
  try {
    // 这里进行了获取
    MappedStatement ms = configuration.getMappedStatement(statement);
    return executor.query(ms, wrapCollection(parameter), rowBounds, handler);
  } catch (Exception e) {
    throw ExceptionFactory.wrapException("Error querying database.  Cause: " + e, e);
  } finally {
    ErrorContext.instance().reset();
  }
}

发表于 分类于 ， 阅读次数： Disqus：

mybatis是我们比较常用的orm框架，下面是官网的介绍

MyBatis 是一款优秀的持久层框架，它支持自定义 SQL、存储过程以及高级映射。MyBatis 免除了几乎所有的 JDBC 代码以及设置参数和获取结果集的工作。MyBatis 可以通过简单的 XML 或注解来配置和映射原始类型、接口和 Java POJO（Plain Old Java Objects，普通老式 Java 对象）为数据库中的记录。

mybatis一大特点，或者说比较为人熟知的应该就是比 hibernate 是更轻量化，为国人所爱好的orm框架，对于hibernate目前还没有深入的拆解过，后续可以也写一下，在使用体验上觉得是个比较精巧的框架，看代码也比较容易，所以就想写个系列，第一篇先是介绍下使用
根据官网的文档上我们先来尝试一下简单使用
首先我们有个简单的配置，这个文件是mybatis-config.xml

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
        PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
        "https://mybatis.org/dtd/mybatis-3-config.dtd">
<configuration>
    <!-- 需要加入的properties-->
    <properties resource="application-development.properties"/>
    <!-- 指出使用哪个环境，默认是development-->
    <environments default="development">
        <environment id="development">
        <!-- 指定事务管理器类型-->
            <transactionManager type="JDBC"/>
            <!-- 指定数据源类型-->
            <dataSource type="POOLED">
                <!-- 下面就是具体的参数占位了-->
                <property name="driver" value="${driver}"/>
                <property name="url" value="${url}"/>
                <property name="username" value="${username}"/>
                <property name="password" value="${password}"/>
            </dataSource>
        </environment>
    </environments>
    <mappers>
        <!-- 指定mapper xml的位置或文件-->
        <mapper resource="mapper/StudentMapper.xml"/>
    </mappers>
</configuration>

在代码里创建mybatis里重要入口

1
2
3
String resource = "mybatis-config.xml";
InputStream inputStream = Resources.getResourceAsStream(resource);
SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(inputStream);

然后我们上面的StudentMapper.xml

1
2
3
4
5
6
7
8
9
<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper
        PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
        "https://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="com.nicksxs.mybatisdemo.StudentMapper">
    <select id="selectStudent" resultType="com.nicksxs.mybatisdemo.StudentDO">
        select * from student where id = #{id}
    </select>
</mapper>

那么我们就要使用这个mapper，

1
2
3
4
5
6
7
8
9
String resource = "mybatis-config.xml";
InputStream inputStream = Resources.getResourceAsStream(resource);
SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(inputStream);
try (SqlSession session = sqlSessionFactory.openSession()) {
    StudentDO studentDO = session.selectOne("com.nicksxs.mybatisdemo.StudentMapper.selectStudent", 1);
    System.out.println("id is " + studentDO.getId() + " name is " +studentDO.getName());
} catch (Exception e) {
    e.printStackTrace();
}

sqlSessionFactory是sqlSession的工厂，我们可以通过sqlSessionFactory来创建sqlSession，而SqlSession 提供了在数据库执行 SQL 命令所需的所有方法。你可以通过 SqlSession 实例来直接执行已映射的 SQL 语句。可以看到mapper.xml中有定义mapper的namespace，就可以通过session.selectOne()传入namespace+id来调用这个方法
但是这样调用比较不合理的点，或者说按后面mybatis优化之后我们可以指定mapper接口

1
2
3
4
public interface StudentMapper {

    public StudentDO selectStudent(Long id);
}

就可以可以通过mapper接口获取方法，这样就不用涉及到未知的变量转换等异常

1
2
3
4
5
6
7
try (SqlSession session = sqlSessionFactory.openSession()) {
    StudentMapper mapper = session.getMapper(StudentMapper.class);
    StudentDO studentDO = mapper.selectStudent(1L);
    System.out.println("id is " + studentDO.getId() + " name is " +studentDO.getName());
} catch (Exception e) {
    e.printStackTrace();
}

这一篇咱们先介绍下简单的使用，后面可以先介绍下这些的原理。

发表于 分类于 阅读次数： Disqus：

powershell创建数组也很方便
可以这样

1
$nums=2,0,1,2

顺便可以用下我们上次学到的gettype()

如果是想创建连续数字的数组还可以用这个方便的方法

1
$nums=1..5


而且数组还可以存放各种类型的数据

1
$array=1,"哈哈",([System.Guid]::NewGuid()),(get-date)


还有判断类型可以用-is

创建一个空数组

1
$array=@()


数组添加元素

1
$array+="a"


数组删除元素

1
2
$a=1..4
$a=$a[0..1]+$a[3]

0%
