发表于 分类于 ， 阅读次数： Disqus：

DataSource 作为数据库查询的最重要的数据源，在 mybatis 中也展开来说下
首先是解析的过程

1
SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(inputStream);

在构建 SqlSessionFactory 也就是 DefaultSqlSessionFactory 的时候，

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
public SqlSessionFactory build(InputStream inputStream) {
    return build(inputStream, null, null);
  }
public SqlSessionFactory build(InputStream inputStream, String environment, Properties properties) {
    try {
      XMLConfigBuilder parser = new XMLConfigBuilder(inputStream, environment, properties);
      return build(parser.parse());
    } catch (Exception e) {
      throw ExceptionFactory.wrapException("Error building SqlSession.", e);
    } finally {
      ErrorContext.instance().reset();
      try {
      	if (inputStream != null) {
      	  inputStream.close();
      	}
      } catch (IOException e) {
        // Intentionally ignore. Prefer previous error.
      }
    }
  }

前面也说过，就是解析 mybatis-config.xml 成 Configuration

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
public Configuration parse() {
  if (parsed) {
    throw new BuilderException("Each XMLConfigBuilder can only be used once.");
  }
  parsed = true;
  parseConfiguration(parser.evalNode("/configuration"));
  return configuration;
}
private void parseConfiguration(XNode root) {
  try {
    // issue #117 read properties first
    propertiesElement(root.evalNode("properties"));
    Properties settings = settingsAsProperties(root.evalNode("settings"));
    loadCustomVfs(settings);
    loadCustomLogImpl(settings);
    typeAliasesElement(root.evalNode("typeAliases"));
    pluginElement(root.evalNode("plugins"));
    objectFactoryElement(root.evalNode("objectFactory"));
    objectWrapperFactoryElement(root.evalNode("objectWrapperFactory"));
    reflectorFactoryElement(root.evalNode("reflectorFactory"));
    settingsElement(settings);
    // read it after objectFactory and objectWrapperFactory issue #631
    // -------------> 是在这里解析了DataSource
    environmentsElement(root.evalNode("environments"));
    databaseIdProviderElement(root.evalNode("databaseIdProvider"));
    typeHandlerElement(root.evalNode("typeHandlers"));
    mapperElement(root.evalNode("mappers"));
  } catch (Exception e) {
    throw new BuilderException("Error parsing SQL Mapper Configuration. Cause: " + e, e);
  }
}

环境解析了这一块的内容

1
2
3
4
5
6
7
8
9
10
11
<environments default="development">
        <environment id="development">
            <transactionManager type="JDBC"/>
            <dataSource type="POOLED">
                <property name="driver" value="${driver}"/>
                <property name="url" value="${url}"/>
                <property name="username" value="${username}"/>
                <property name="password" value="${password}"/>
            </dataSource>
        </environment>
    </environments>

解析也是自上而下的，

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
private void environmentsElement(XNode context) throws Exception {
  if (context != null) {
    if (environment == null) {
      environment = context.getStringAttribute("default");
    }
    for (XNode child : context.getChildren()) {
      String id = child.getStringAttribute("id");
      if (isSpecifiedEnvironment(id)) {
        TransactionFactory txFactory = transactionManagerElement(child.evalNode("transactionManager"));
        DataSourceFactory dsFactory = dataSourceElement(child.evalNode("dataSource"));
        DataSource dataSource = dsFactory.getDataSource();
        Environment.Builder environmentBuilder = new Environment.Builder(id)
            .transactionFactory(txFactory)
            .dataSource(dataSource);
        configuration.setEnvironment(environmentBuilder.build());
        break;
      }
    }
  }
}

前面第一步是解析事务管理器元素

1
2
3
4
5
6
7
8
9
10
private TransactionFactory transactionManagerElement(XNode context) throws Exception {
  if (context != null) {
    String type = context.getStringAttribute("type");
    Properties props = context.getChildrenAsProperties();
    TransactionFactory factory = (TransactionFactory) resolveClass(type).getDeclaredConstructor().newInstance();
    factory.setProperties(props);
    return factory;
  }
  throw new BuilderException("Environment declaration requires a TransactionFactory.");
}

而这里的 resolveClass 其实就使用了上一篇的 typeAliases 系统，这里是使用了 JdbcTransactionFactory 作为事务管理器，
后面的就是 DataSourceFactory 的创建也是 DataSource 的创建

1
2
3
4
5
6
7
8
9
10
private DataSourceFactory dataSourceElement(XNode context) throws Exception {
  if (context != null) {
    String type = context.getStringAttribute("type");
    Properties props = context.getChildrenAsProperties();
    DataSourceFactory factory = (DataSourceFactory) resolveClass(type).getDeclaredConstructor().newInstance();
    factory.setProperties(props);
    return factory;
  }
  throw new BuilderException("Environment declaration requires a DataSourceFactory.");
}

因为在config文件中设置了Pooled，所以对应创建的就是 PooledDataSourceFactory
但是这里其实有个比较需要注意的，mybatis 这里的其实是继承了 UnpooledDataSourceFactory
将基础方法都放在了 UnpooledDataSourceFactory 中

1
2
3
4
5
6
7
public class PooledDataSourceFactory extends UnpooledDataSourceFactory {

  public PooledDataSourceFactory() {
    this.dataSource = new PooledDataSource();
  }

}

这里只保留了在构造方法里创建 DataSource
而这个 PooledDataSource 虽然没有直接继承 UnpooledDataSource，但其实
在构造方法里也是

1
2
3
public PooledDataSource() {
  dataSource = new UnpooledDataSource();
}

至于为什么这么做呢应该也是考虑到能比较多的复用代码，因为 Pooled 其实跟 Unpooled 最重要的差别就在于是不是每次都重开连接
使用连接池能够让应用在有大量查询的时候不用反复创建连接，省去了建联的网络等开销，Unpooled就是完成与数据库的连接，并可以获取该连接
主要的代码

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
@Override
public Connection getConnection() throws SQLException {
  return doGetConnection(username, password);
}

@Override
public Connection getConnection(String username, String password) throws SQLException {
  return doGetConnection(username, password);
}
private Connection doGetConnection(String username, String password) throws SQLException {
  Properties props = new Properties();
  if (driverProperties != null) {
    props.putAll(driverProperties);
  }
  if (username != null) {
    props.setProperty("user", username);
  }
  if (password != null) {
    props.setProperty("password", password);
  }
  return doGetConnection(props);
}
private Connection doGetConnection(Properties properties) throws SQLException {
  initializeDriver();
  Connection connection = DriverManager.getConnection(url, properties);
  configureConnection(connection);
  return connection;
}

而对于Pooled就会处理池化的逻辑

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
private PooledConnection popConnection(String username, String password) throws SQLException {
    boolean countedWait = false;
    PooledConnection conn = null;
    long t = System.currentTimeMillis();
    int localBadConnectionCount = 0;

    while (conn == null) {
      lock.lock();
      try {
        if (!state.idleConnections.isEmpty()) {
          // Pool has available connection
          conn = state.idleConnections.remove(0);
          if (log.isDebugEnabled()) {
            log.debug("Checked out connection " + conn.getRealHashCode() + " from pool.");
          }
        } else {
          // Pool does not have available connection
          if (state.activeConnections.size() < poolMaximumActiveConnections) {
            // Can create new connection
            conn = new PooledConnection(dataSource.getConnection(), this);
            if (log.isDebugEnabled()) {
              log.debug("Created connection " + conn.getRealHashCode() + ".");
            }
          } else {
            // Cannot create new connection
            PooledConnection oldestActiveConnection = state.activeConnections.get(0);
            long longestCheckoutTime = oldestActiveConnection.getCheckoutTime();
            if (longestCheckoutTime > poolMaximumCheckoutTime) {
              // Can claim overdue connection
              state.claimedOverdueConnectionCount++;
              state.accumulatedCheckoutTimeOfOverdueConnections += longestCheckoutTime;
              state.accumulatedCheckoutTime += longestCheckoutTime;
              state.activeConnections.remove(oldestActiveConnection);
              if (!oldestActiveConnection.getRealConnection().getAutoCommit()) {
                try {
                  oldestActiveConnection.getRealConnection().rollback();
                } catch (SQLException e) {
                  /*
                     Just log a message for debug and continue to execute the following
                     statement like nothing happened.
                     Wrap the bad connection with a new PooledConnection, this will help
                     to not interrupt current executing thread and give current thread a
                     chance to join the next competition for another valid/good database
                     connection. At the end of this loop, bad {@link @conn} will be set as null.
                   */
                  log.debug("Bad connection. Could not roll back");
                }
              }
              conn = new PooledConnection(oldestActiveConnection.getRealConnection(), this);
              conn.setCreatedTimestamp(oldestActiveConnection.getCreatedTimestamp());
              conn.setLastUsedTimestamp(oldestActiveConnection.getLastUsedTimestamp());
              oldestActiveConnection.invalidate();
              if (log.isDebugEnabled()) {
                log.debug("Claimed overdue connection " + conn.getRealHashCode() + ".");
              }
            } else {
              // Must wait
              try {
                if (!countedWait) {
                  state.hadToWaitCount++;
                  countedWait = true;
                }
                if (log.isDebugEnabled()) {
                  log.debug("Waiting as long as " + poolTimeToWait + " milliseconds for connection.");
                }
                long wt = System.currentTimeMillis();
                condition.await(poolTimeToWait, TimeUnit.MILLISECONDS);
                state.accumulatedWaitTime += System.currentTimeMillis() - wt;
              } catch (InterruptedException e) {
                // set interrupt flag
                Thread.currentThread().interrupt();
                break;
              }
            }
          }
        }
        if (conn != null) {
          // ping to server and check the connection is valid or not
          if (conn.isValid()) {
            if (!conn.getRealConnection().getAutoCommit()) {
              conn.getRealConnection().rollback();
            }
            conn.setConnectionTypeCode(assembleConnectionTypeCode(dataSource.getUrl(), username, password));
            conn.setCheckoutTimestamp(System.currentTimeMillis());
            conn.setLastUsedTimestamp(System.currentTimeMillis());
            state.activeConnections.add(conn);
            state.requestCount++;
            state.accumulatedRequestTime += System.currentTimeMillis() - t;
          } else {
            if (log.isDebugEnabled()) {
              log.debug("A bad connection (" + conn.getRealHashCode() + ") was returned from the pool, getting another connection.");
            }
            state.badConnectionCount++;
            localBadConnectionCount++;
            conn = null;
            if (localBadConnectionCount > (poolMaximumIdleConnections + poolMaximumLocalBadConnectionTolerance)) {
              if (log.isDebugEnabled()) {
                log.debug("PooledDataSource: Could not get a good connection to the database.");
              }
              throw new SQLException("PooledDataSource: Could not get a good connection to the database.");
            }
          }
        }
      } finally {
        lock.unlock();
      }

    }

    if (conn == null) {
      if (log.isDebugEnabled()) {
        log.debug("PooledDataSource: Unknown severe error condition.  The connection pool returned a null connection.");
      }
      throw new SQLException("PooledDataSource: Unknown severe error condition.  The connection pool returned a null connection.");
    }

    return conn;
  }

它的入口不是个get方法，而是pop，从含义来来讲就不一样
org.apache.ibatis.datasource.pooled.PooledDataSource#getConnection()

1
2
3
4
@Override
public Connection getConnection() throws SQLException {
  return popConnection(dataSource.getUsername(), dataSource.getPassword()).getProxyConnection();
}

对于具体怎么获取连接我们可以下一篇具体讲下

发表于 分类于 ， 阅读次数： Disqus：

其实前面已经聊到过这个概念，在mybatis的配置中，以及一些初始化逻辑都是用了typeAliases，

1
2
3
4
5
6
7
8
<typeAliases>
  <typeAlias alias="Author" type="domain.blog.Author"/>
  <typeAlias alias="Blog" type="domain.blog.Blog"/>
  <typeAlias alias="Comment" type="domain.blog.Comment"/>
  <typeAlias alias="Post" type="domain.blog.Post"/>
  <typeAlias alias="Section" type="domain.blog.Section"/>
  <typeAlias alias="Tag" type="domain.blog.Tag"/>
</typeAliases>

可以在这里注册类型别名，然后在mybatis中配置使用时，可以简化这些类型的使用，其底层逻辑主要是一个map，

1
2
3
public class TypeAliasRegistry {

  private final Map<String, Class<?>> typeAliases = new HashMap<>();

以string作为key，class对象作为value，比如我们在一开始使用的配置文件

1
2
3
4
5
6
<dataSource type="POOLED">
    <property name="driver" value="${driver}"/>
    <property name="url" value="${url}"/>
    <property name="username" value="${username}"/>
    <property name="password" value="${password}"/>
</dataSource>

这里使用的dataSource是POOLED，那它肯定是个别名或者需要对应处理
而这个别名就是在Configuration的构造方法里初始化

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
public Configuration() {
    typeAliasRegistry.registerAlias("JDBC", JdbcTransactionFactory.class);
    typeAliasRegistry.registerAlias("MANAGED", ManagedTransactionFactory.class);

    typeAliasRegistry.registerAlias("JNDI", JndiDataSourceFactory.class);
    typeAliasRegistry.registerAlias("POOLED", PooledDataSourceFactory.class);
    typeAliasRegistry.registerAlias("UNPOOLED", UnpooledDataSourceFactory.class);

    typeAliasRegistry.registerAlias("PERPETUAL", PerpetualCache.class);
    typeAliasRegistry.registerAlias("FIFO", FifoCache.class);
    typeAliasRegistry.registerAlias("LRU", LruCache.class);
    typeAliasRegistry.registerAlias("SOFT", SoftCache.class);
    typeAliasRegistry.registerAlias("WEAK", WeakCache.class);

    typeAliasRegistry.registerAlias("DB_VENDOR", VendorDatabaseIdProvider.class);

    typeAliasRegistry.registerAlias("XML", XMLLanguageDriver.class);
    typeAliasRegistry.registerAlias("RAW", RawLanguageDriver.class);

    typeAliasRegistry.registerAlias("SLF4J", Slf4jImpl.class);
    typeAliasRegistry.registerAlias("COMMONS_LOGGING", JakartaCommonsLoggingImpl.class);
    typeAliasRegistry.registerAlias("LOG4J", Log4jImpl.class);
    typeAliasRegistry.registerAlias("LOG4J2", Log4j2Impl.class);
    typeAliasRegistry.registerAlias("JDK_LOGGING", Jdk14LoggingImpl.class);
    typeAliasRegistry.registerAlias("STDOUT_LOGGING", StdOutImpl.class);
    typeAliasRegistry.registerAlias("NO_LOGGING", NoLoggingImpl.class);

    typeAliasRegistry.registerAlias("CGLIB", CglibProxyFactory.class);
    typeAliasRegistry.registerAlias("JAVASSIST", JavassistProxyFactory.class);

    languageRegistry.setDefaultDriverClass(XMLLanguageDriver.class);
    languageRegistry.register(RawLanguageDriver.class);
  }

正是通过typeAliasRegistry.registerAlias("POOLED", PooledDataSourceFactory.class);这一行，注册了
POOLED对应的别名类型是PooledDataSourceFactory.class
具体的注册方法是在

1
2
3
4
5
6
7
8
9
10
11
12
13
14
public void registerAlias(String alias, Class<?> value) {
  if (alias == null) {
    throw new TypeException("The parameter alias cannot be null");
  }
  // issue #748
  // 转换成小写，
  String key = alias.toLowerCase(Locale.ENGLISH);
  // 判断是否已经注册过了
  if (typeAliases.containsKey(key) && typeAliases.get(key) != null && !typeAliases.get(key).equals(value)) {
    throw new TypeException("The alias '" + alias + "' is already mapped to the value '" + typeAliases.get(key).getName() + "'.");
  }
  // 放进map里
  typeAliases.put(key, value);
}

而获取的逻辑在这

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
public <T> Class<T> resolveAlias(String string) {
    try {
      if (string == null) {
        return null;
      }
      // issue #748
      // 同样的转成小写
      String key = string.toLowerCase(Locale.ENGLISH);
      Class<T> value;
      if (typeAliases.containsKey(key)) {
        value = (Class<T>) typeAliases.get(key);
      } else {
        // 这里还有从路径下处理的逻辑
        value = (Class<T>) Resources.classForName(string);
      }
      return value;
    } catch (ClassNotFoundException e) {
      throw new TypeException("Could not resolve type alias '" + string + "'.  Cause: " + e, e);
    }
  }

逻辑比较简单，但是在mybatis中也是不可或缺的一块概念

发表于 分类于 阅读次数： Disqus：

这次单独介绍下docker体系里非常重要的cgroup，docker对资源的限制也是基于cgroup构建的，
简单尝试
新建一个shell脚本

1
2
3
4
#!/bin/bash
while true;do
    echo "1"
done

直接执行的话就是单核100%的cpu

首先在cgroup下面建个目录

1
mkdir -p /sys/fs/cgroup/cpu/sxs_test/

查看目录下的文件

其中cpuacct开头的表示cpu相关的统计信息，
我们要配置cpu的额度，是在cpu.cfs_quota_us中

1
echo 2000 > /sys/fs/cgroup/cpu/sxs_test/cpu.cfs_quota_us

这样表示可以使用2%的cpu，总的配额是在cpu.cfs_period_us中

然后将当前进程输入到cgroup.procs,

1
echo $$ > /sys/fs/cgroup/cpu/sxs_test/cgroup.procs

这样就会自动继承当前进程产生的新进程
再次执行就可以看到cpu被限制了

发表于 分类于 ， 阅读次数： Disqus：

执行细节
首先设置了默认的languageDriver
org/mybatis/mybatis/3.5.11/mybatis-3.5.11-sources.jar!/org/apache/ibatis/session/Configuration.java:215
在configuration的构造方法里

1
languageRegistry.setDefaultDriverClass(XMLLanguageDriver.class);

而在
org.apache.ibatis.builder.xml.XMLStatementBuilder#parseStatementNode
中，创建了sqlSource，这里就会根据前面的 LanguageDriver 的实现选择对应的 sqlSource ，

1
SqlSource sqlSource = langDriver.createSqlSource(configuration, context, parameterTypeClass);

createSqlSource 就会调用

1
2
3
4
5
@Override
public SqlSource createSqlSource(Configuration configuration, XNode script, Class<?> parameterType) {
  XMLScriptBuilder builder = new XMLScriptBuilder(configuration, script, parameterType);
  return builder.parseScriptNode();
}

再往下的逻辑在 parseScriptNode 中，org.apache.ibatis.scripting.xmltags.XMLScriptBuilder#parseScriptNode

1
2
3
4
5
6
7
8
9
10
public SqlSource parseScriptNode() {
  MixedSqlNode rootSqlNode = parseDynamicTags(context);
  SqlSource sqlSource;
  if (isDynamic) {
    sqlSource = new DynamicSqlSource(configuration, rootSqlNode);
  } else {
    sqlSource = new RawSqlSource(configuration, rootSqlNode, parameterType);
  }
  return sqlSource;
}

首先要解析dynamicTag，调用了org.apache.ibatis.scripting.xmltags.XMLScriptBuilder#parseDynamicTags

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
protected MixedSqlNode parseDynamicTags(XNode node) {
    List<SqlNode> contents = new ArrayList<>();
    NodeList children = node.getNode().getChildNodes();
    for (int i = 0; i < children.getLength(); i++) {
      XNode child = node.newXNode(children.item(i));
      if (child.getNode().getNodeType() == Node.CDATA_SECTION_NODE || child.getNode().getNodeType() == Node.TEXT_NODE) {
        String data = child.getStringBody("");
        TextSqlNode textSqlNode = new TextSqlNode(data);
        // ---------> 主要是这边的逻辑
        if (textSqlNode.isDynamic()) {
          contents.add(textSqlNode);
          isDynamic = true;
        } else {
          contents.add(new StaticTextSqlNode(data));
        }
      } else if (child.getNode().getNodeType() == Node.ELEMENT_NODE) { // issue #628
        String nodeName = child.getNode().getNodeName();
        NodeHandler handler = nodeHandlerMap.get(nodeName);
        if (handler == null) {
          throw new BuilderException("Unknown element <" + nodeName + "> in SQL statement.");
        }
        handler.handleNode(child, contents);
        isDynamic = true;
      }
    }
    return new MixedSqlNode(contents);
  }

判断是否是动态sql，调用了org.apache.ibatis.scripting.xmltags.TextSqlNode#isDynamic

1
2
3
4
5
6
7
public boolean isDynamic() {
  DynamicCheckerTokenParser checker = new DynamicCheckerTokenParser();
  // ----------> 主要是这里的方法
  GenericTokenParser parser = createParser(checker);
  parser.parse(text);
  return checker.isDynamic();
}

创建parser的时候可以看到这个parser是干了啥，其实就是找有没有${ , }

1
2
3
private GenericTokenParser createParser(TokenHandler handler) {
  return new GenericTokenParser("${", "}", handler);
}

如果是的话，就在上面把 isDynamic 设置为true 如果是true 的话就创建 DynamicSqlSource

1
sqlSource = new DynamicSqlSource(configuration, rootSqlNode);

如果不是的话就创建RawSqlSource

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
sqlSource = new RawSqlSource(configuration, rootSqlNode, parameterType);
```java

但是这不是一个真实可用的 `sqlSource` ，
实际创建的时候会走到这
```java
public RawSqlSource(Configuration configuration, SqlNode rootSqlNode, Class<?> parameterType) {
    this(configuration, getSql(configuration, rootSqlNode), parameterType);
  }

  public RawSqlSource(Configuration configuration, String sql, Class<?> parameterType) {
    SqlSourceBuilder sqlSourceParser = new SqlSourceBuilder(configuration);
    Class<?> clazz = parameterType == null ? Object.class : parameterType;
    sqlSource = sqlSourceParser.parse(sql, clazz, new HashMap<>());
  }

具体的sqlSource是通过org.apache.ibatis.builder.SqlSourceBuilder#parse 创建的
具体的代码逻辑是

1
2
3
4
5
6
7
8
9
10
11
public SqlSource parse(String originalSql, Class<?> parameterType, Map<String, Object> additionalParameters) {
  ParameterMappingTokenHandler handler = new ParameterMappingTokenHandler(configuration, parameterType, additionalParameters);
  GenericTokenParser parser = new GenericTokenParser("#{", "}", handler);
  String sql;
  if (configuration.isShrinkWhitespacesInSql()) {
    sql = parser.parse(removeExtraWhitespaces(originalSql));
  } else {
    sql = parser.parse(originalSql);
  }
  return new StaticSqlSource(configuration, sql, handler.getParameterMappings());
}

这里创建的其实是StaticSqlSource ,多带一句前面的parser是将原来这样select * from student where id = #{id} 的 sql 解析成了select * from student where id = ? 然后创建了StaticSqlSource

1
2
3
4
5
public StaticSqlSource(Configuration configuration, String sql, List<ParameterMapping> parameterMappings) {
  this.sql = sql;
  this.parameterMappings = parameterMappings;
  this.configuration = configuration;
}

为什么前面要讲这么多好像没什么关系的代码呢，其实在最开始我们执行sql的代码中

1
2
3
4
5
6
@Override
  public <E> List<E> query(MappedStatement ms, Object parameterObject, RowBounds rowBounds, ResultHandler resultHandler) throws SQLException {
    BoundSql boundSql = ms.getBoundSql(parameterObject);
    CacheKey key = createCacheKey(ms, parameterObject, rowBounds, boundSql);
    return query(ms, parameterObject, rowBounds, resultHandler, key, boundSql);
  }

这里获取了BoundSql，而BoundSql是怎么来的呢，首先调用了org.apache.ibatis.mapping.MappedStatement#getBoundSql

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
public BoundSql getBoundSql(Object parameterObject) {
    BoundSql boundSql = sqlSource.getBoundSql(parameterObject);
    List<ParameterMapping> parameterMappings = boundSql.getParameterMappings();
    if (parameterMappings == null || parameterMappings.isEmpty()) {
      boundSql = new BoundSql(configuration, boundSql.getSql(), parameterMap.getParameterMappings(), parameterObject);
    }

    // check for nested result maps in parameter mappings (issue #30)
    for (ParameterMapping pm : boundSql.getParameterMappings()) {
      String rmId = pm.getResultMapId();
      if (rmId != null) {
        ResultMap rm = configuration.getResultMap(rmId);
        if (rm != null) {
          hasNestedResultMaps |= rm.hasNestedResultMaps();
        }
      }
    }

    return boundSql;
  }

而我们从上面的解析中可以看到这里的sqlSource是一层RawSqlSource , 它的getBoundSql又是调用内部的sqlSource的方法

1
2
3
4
@Override
public BoundSql getBoundSql(Object parameterObject) {
  return sqlSource.getBoundSql(parameterObject);
}

内部的sqlSource 就是StaticSqlSource ，

1
2
3
4
@Override
public BoundSql getBoundSql(Object parameterObject) {
  return new BoundSql(configuration, sql, parameterMappings, parameterObject);
}

这个BoundSql的内容也比较简单

1
2
3
4
5
6
7
public BoundSql(Configuration configuration, String sql, List<ParameterMapping> parameterMappings, Object parameterObject) {
  this.sql = sql;
  this.parameterMappings = parameterMappings;
  this.parameterObject = parameterObject;
  this.additionalParameters = new HashMap<>();
  this.metaParameters = configuration.newMetaObject(additionalParameters);
}

而上次在这边org.apache.ibatis.executor.SimpleExecutor#doQuery 的时候落了个东西，就是StatementHandler的逻辑

1
2
3
4
5
6
7
8
9
10
11
12
@Override
public <E> List<E> doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
  Statement stmt = null;
  try {
    Configuration configuration = ms.getConfiguration();
    StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
    stmt = prepareStatement(handler, ms.getStatementLog());
    return handler.query(stmt, resultHandler);
  } finally {
    closeStatement(stmt);
  }
}

它是通过statementType来区分应该使用哪个statementHandler，我们这使用的就是PreparedStatementHandler

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
public RoutingStatementHandler(Executor executor, MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) {

  switch (ms.getStatementType()) {
    case STATEMENT:
      delegate = new SimpleStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
      break;
    case PREPARED:
      delegate = new PreparedStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
      break;
    case CALLABLE:
      delegate = new CallableStatementHandler(executor, ms, parameter, rowBounds, resultHandler, boundSql);
      break;
    default:
      throw new ExecutorException("Unknown statement type: " + ms.getStatementType());
  }

}

所以上次有个细节可以补充，这边的doQuery里面的handler.query 应该是调用了PreparedStatementHandler 的query方法

1
2
3
4
5
6
7
8
9
10
11
12
@Override
public <E> List<E> doQuery(MappedStatement ms, Object parameter, RowBounds rowBounds, ResultHandler resultHandler, BoundSql boundSql) throws SQLException {
  Statement stmt = null;
  try {
    Configuration configuration = ms.getConfiguration();
    StatementHandler handler = configuration.newStatementHandler(wrapper, ms, parameter, rowBounds, resultHandler, boundSql);
    stmt = prepareStatement(handler, ms.getStatementLog());
    return handler.query(stmt, resultHandler);
  } finally {
    closeStatement(stmt);
  }
}

因为上面prepareStatement中getConnection拿到connection是com.mysql.cj.jdbc.ConnectionImpl#ConnectionImpl(com.mysql.cj.conf.HostInfo)

1
2
3
4
5
6
@Override
public <E> List<E> query(Statement statement, ResultHandler resultHandler) throws SQLException {
  PreparedStatement ps = (PreparedStatement) statement;
  ps.execute();
  return resultSetHandler.handleResultSets(ps);
}

那又为什么是这个呢，可以在网上找，我们在mybatis-config.xml里配置的

1
<transactionManager type="JDBC"/>

因此在parseConfiguration中配置environment时

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
private void parseConfiguration(XNode root) {
    try {
      // issue #117 read properties first
      propertiesElement(root.evalNode("properties"));
      Properties settings = settingsAsProperties(root.evalNode("settings"));
      loadCustomVfs(settings);
      loadCustomLogImpl(settings);
      typeAliasesElement(root.evalNode("typeAliases"));
      pluginElement(root.evalNode("plugins"));
      objectFactoryElement(root.evalNode("objectFactory"));
      objectWrapperFactoryElement(root.evalNode("objectWrapperFactory"));
      reflectorFactoryElement(root.evalNode("reflectorFactory"));
      settingsElement(settings);
      // read it after objectFactory and objectWrapperFactory issue #631
      // ----------> 就是这里
      environmentsElement(root.evalNode("environments"));
      databaseIdProviderElement(root.evalNode("databaseIdProvider"));
      typeHandlerElement(root.evalNode("typeHandlers"));
      mapperElement(root.evalNode("mappers"));
    } catch (Exception e) {
      throw new BuilderException("Error parsing SQL Mapper Configuration. Cause: " + e, e);
    }
  }

调用的这个方法通过获取xml中的transactionManager 配置的类型，也就是JDBC

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
private void environmentsElement(XNode context) throws Exception {
  if (context != null) {
    if (environment == null) {
      environment = context.getStringAttribute("default");
    }
    for (XNode child : context.getChildren()) {
      String id = child.getStringAttribute("id");
      if (isSpecifiedEnvironment(id)) {
        // -------> 找到这里
        TransactionFactory txFactory = transactionManagerElement(child.evalNode("transactionManager"));
        DataSourceFactory dsFactory = dataSourceElement(child.evalNode("dataSource"));
        DataSource dataSource = dsFactory.getDataSource();
        Environment.Builder environmentBuilder = new Environment.Builder(id)
            .transactionFactory(txFactory)
            .dataSource(dataSource);
        configuration.setEnvironment(environmentBuilder.build());
        break;
      }
    }
  }
}

是通过以下方法获取的，

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
// 方法全限定名 org.apache.ibatis.builder.xml.XMLConfigBuilder#transactionManagerElement
private TransactionFactory transactionManagerElement(XNode context) throws Exception {
    if (context != null) {
      String type = context.getStringAttribute("type");
      Properties props = context.getChildrenAsProperties();
      TransactionFactory factory = (TransactionFactory) resolveClass(type).getDeclaredConstructor().newInstance();
      factory.setProperties(props);
      return factory;
    }
    throw new BuilderException("Environment declaration requires a TransactionFactory.");
  }

// 方法全限定名 org.apache.ibatis.builder.BaseBuilder#resolveClass
protected <T> Class<? extends T> resolveClass(String alias) {
    if (alias == null) {
      return null;
    }
    try {
      return resolveAlias(alias);
    } catch (Exception e) {
      throw new BuilderException("Error resolving class. Cause: " + e, e);
    }
  }

// 方法全限定名 org.apache.ibatis.builder.BaseBuilder#resolveAlias
  protected <T> Class<? extends T> resolveAlias(String alias) {
    return typeAliasRegistry.resolveAlias(alias);
  }
// 方法全限定名 org.apache.ibatis.type.TypeAliasRegistry#resolveAlias
  public <T> Class<T> resolveAlias(String string) {
    try {
      if (string == null) {
        return null;
      }
      // issue #748
      String key = string.toLowerCase(Locale.ENGLISH);
      Class<T> value;
      if (typeAliases.containsKey(key)) {
        value = (Class<T>) typeAliases.get(key);
      } else {
        value = (Class<T>) Resources.classForName(string);
      }
      return value;
    } catch (ClassNotFoundException e) {
      throw new TypeException("Could not resolve type alias '" + string + "'.  Cause: " + e, e);
    }
  }

而通过JDBC获取得是啥的，就是在Configuration的构造方法里写了的JdbcTransactionFactory

1
2
public Configuration() {
  typeAliasRegistry.registerAlias("JDBC", JdbcTransactionFactory.class);

所以我们在这

1
2
3
4
5
private SqlSession openSessionFromDataSource(ExecutorType execType, TransactionIsolationLevel level, boolean autoCommit) {
  Transaction tx = null;
  try {
    final Environment environment = configuration.getEnvironment();
    final TransactionFactory transactionFactory = getTransactionFactoryFromEnvironment(environment);

获得到的TransactionFactory 就是 JdbcTransactionFactory ，而后

1
2
3
4
5
6
7
8
9
tx = transactionFactory.newTransaction(environment.getDataSource(), level, autoCommit);
```java

创建的transaction就是JdbcTransaction
```java
  @Override
  public Transaction newTransaction(DataSource ds, TransactionIsolationLevel level, boolean autoCommit) {
    return new JdbcTransaction(ds, level, autoCommit, skipSetAutoCommitOnClose);
  }

然后我们再会上去看代码getConnection ,

1
2
3
4
5
6
7
8
9
protected Connection getConnection(Log statementLog) throws SQLException {
  // -------> 这里的transaction就是JdbcTransaction
  Connection connection = transaction.getConnection();
  if (statementLog.isDebugEnabled()) {
    return ConnectionLogger.newInstance(connection, statementLog, queryStack);
  } else {
    return connection;
  }
}

即调用了

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
  @Override
  public Connection getConnection() throws SQLException {
    if (connection == null) {
      openConnection();
    }
    return connection;
  }

  protected void openConnection() throws SQLException {
    if (log.isDebugEnabled()) {
      log.debug("Opening JDBC Connection");
    }
    connection = dataSource.getConnection();
    if (level != null) {
      connection.setTransactionIsolation(level.getLevel());
    }
    setDesiredAutoCommit(autoCommit);
  }
  @Override
  public Connection getConnection() throws SQLException {
    return popConnection(dataSource.getUsername(), dataSource.getPassword()).getProxyConnection();
  }

private PooledConnection popConnection(String username, String password) throws SQLException {
    boolean countedWait = false;
    PooledConnection conn = null;
    long t = System.currentTimeMillis();
    int localBadConnectionCount = 0;

    while (conn == null) {
      lock.lock();
      try {
        if (!state.idleConnections.isEmpty()) {
          // Pool has available connection
          conn = state.idleConnections.remove(0);
          if (log.isDebugEnabled()) {
            log.debug("Checked out connection " + conn.getRealHashCode() + " from pool.");
          }
        } else {
          // Pool does not have available connection
          if (state.activeConnections.size() < poolMaximumActiveConnections) {
            // Can create new connection
            // ------------> 走到这里会创建PooledConnection，但是里面会先调用dataSource.getConnection()
            conn = new PooledConnection(dataSource.getConnection(), this);
            if (log.isDebugEnabled()) {
              log.debug("Created connection " + conn.getRealHashCode() + ".");
            }
          } else {
            // Cannot create new connection
            PooledConnection oldestActiveConnection = state.activeConnections.get(0);
            long longestCheckoutTime = oldestActiveConnection.getCheckoutTime();
            if (longestCheckoutTime > poolMaximumCheckoutTime) {
              // Can claim overdue connection
              state.claimedOverdueConnectionCount++;
              state.accumulatedCheckoutTimeOfOverdueConnections += longestCheckoutTime;
              state.accumulatedCheckoutTime += longestCheckoutTime;
              state.activeConnections.remove(oldestActiveConnection);
              if (!oldestActiveConnection.getRealConnection().getAutoCommit()) {
                try {
                  oldestActiveConnection.getRealConnection().rollback();
                } catch (SQLException e) {
                  /*
                     Just log a message for debug and continue to execute the following
                     statement like nothing happened.
                     Wrap the bad connection with a new PooledConnection, this will help
                     to not interrupt current executing thread and give current thread a
                     chance to join the next competition for another valid/good database
                     connection. At the end of this loop, bad {@link @conn} will be set as null.
                   */
                  log.debug("Bad connection. Could not roll back");
                }
              }
              conn = new PooledConnection(oldestActiveConnection.getRealConnection(), this);
              conn.setCreatedTimestamp(oldestActiveConnection.getCreatedTimestamp());
              conn.setLastUsedTimestamp(oldestActiveConnection.getLastUsedTimestamp());
              oldestActiveConnection.invalidate();
              if (log.isDebugEnabled()) {
                log.debug("Claimed overdue connection " + conn.getRealHashCode() + ".");
              }
            } else {
              // Must wait
              try {
                if (!countedWait) {
                  state.hadToWaitCount++;
                  countedWait = true;
                }
                if (log.isDebugEnabled()) {
                  log.debug("Waiting as long as " + poolTimeToWait + " milliseconds for connection.");
                }
                long wt = System.currentTimeMillis();
                condition.await(poolTimeToWait, TimeUnit.MILLISECONDS);
                state.accumulatedWaitTime += System.currentTimeMillis() - wt;
              } catch (InterruptedException e) {
                // set interrupt flag
                Thread.currentThread().interrupt();
                break;
              }
            }
          }
        }
        if (conn != null) {
          // ping to server and check the connection is valid or not
          if (conn.isValid()) {
            if (!conn.getRealConnection().getAutoCommit()) {
              conn.getRealConnection().rollback();
            }
            conn.setConnectionTypeCode(assembleConnectionTypeCode(dataSource.getUrl(), username, password));
            conn.setCheckoutTimestamp(System.currentTimeMillis());
            conn.setLastUsedTimestamp(System.currentTimeMillis());
            state.activeConnections.add(conn);
            state.requestCount++;
            state.accumulatedRequestTime += System.currentTimeMillis() - t;
          } else {
            if (log.isDebugEnabled()) {
              log.debug("A bad connection (" + conn.getRealHashCode() + ") was returned from the pool, getting another connection.");
            }
            state.badConnectionCount++;
            localBadConnectionCount++;
            conn = null;
            if (localBadConnectionCount > (poolMaximumIdleConnections + poolMaximumLocalBadConnectionTolerance)) {
              if (log.isDebugEnabled()) {
                log.debug("PooledDataSource: Could not get a good connection to the database.");
              }
              throw new SQLException("PooledDataSource: Could not get a good connection to the database.");
            }
          }
        }
      } finally {
        lock.unlock();
      }

    }

    if (conn == null) {
      if (log.isDebugEnabled()) {
        log.debug("PooledDataSource: Unknown severe error condition.  The connection pool returned a null connection.");
      }
      throw new SQLException("PooledDataSource: Unknown severe error condition.  The connection pool returned a null connection.");
    }

    return conn;
  }

其实就是调用的

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
// org.apache.ibatis.datasource.unpooled.UnpooledDataSource#getConnection()
  @Override
  public Connection getConnection() throws SQLException {
    return doGetConnection(username, password);
  }
```java

然后就是
```java
private Connection doGetConnection(String username, String password) throws SQLException {
    Properties props = new Properties();
    if (driverProperties != null) {
      props.putAll(driverProperties);
    }
    if (username != null) {
      props.setProperty("user", username);
    }
    if (password != null) {
      props.setProperty("password", password);
    }
    return doGetConnection(props);
  }

继续这个逻辑

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
  private Connection doGetConnection(Properties properties) throws SQLException {
    initializeDriver();
    Connection connection = DriverManager.getConnection(url, properties);
    configureConnection(connection);
    return connection;
  }
    @CallerSensitive
    public static Connection getConnection(String url,
        java.util.Properties info) throws SQLException {

        return (getConnection(url, info, Reflection.getCallerClass()));
    }
private static Connection getConnection(
        String url, java.util.Properties info, Class<?> caller) throws SQLException {
        /*
         * When callerCl is null, we should check the application's
         * (which is invoking this class indirectly)
         * classloader, so that the JDBC driver class outside rt.jar
         * can be loaded from here.
         */
        ClassLoader callerCL = caller != null ? caller.getClassLoader() : null;
        synchronized(DriverManager.class) {
            // synchronize loading of the correct classloader.
            if (callerCL == null) {
                callerCL = Thread.currentThread().getContextClassLoader();
            }
        }

        if(url == null) {
            throw new SQLException("The url cannot be null", "08001");
        }

        println("DriverManager.getConnection(\"" + url + "\")");

        // Walk through the loaded registeredDrivers attempting to make a connection.
        // Remember the first exception that gets raised so we can reraise it.
        SQLException reason = null;

        for(DriverInfo aDriver : registeredDrivers) {
            // If the caller does not have permission to load the driver then
            // skip it.
            if(isDriverAllowed(aDriver.driver, callerCL)) {
                try {
                    // ----------> driver[className=com.mysql.cj.jdbc.Driver@64030b91]
                    println("    trying " + aDriver.driver.getClass().getName());
                    Connection con = aDriver.driver.connect(url, info);
                    if (con != null) {
                        // Success!
                        println("getConnection returning " + aDriver.driver.getClass().getName());
                        return (con);
                    }
                } catch (SQLException ex) {
                    if (reason == null) {
                        reason = ex;
                    }
                }

            } else {
                println("    skipping: " + aDriver.getClass().getName());
            }

        }

        // if we got here nobody could connect.
        if (reason != null)    {
            println("getConnection failed: " + reason);
            throw reason;
        }

        println("getConnection: no suitable driver found for "+ url);
        throw new SQLException("No suitable driver found for "+ url, "08001");
    }

上面的driver就是driver[className=com.mysql.cj.jdbc.Driver@64030b91]

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
// com.mysql.cj.jdbc.NonRegisteringDriver#connect
public Connection connect(String url, Properties info) throws SQLException {
        try {
            try {
                if (!ConnectionUrl.acceptsUrl(url)) {
                    return null;
                } else {
                    ConnectionUrl conStr = ConnectionUrl.getConnectionUrlInstance(url, info);
                    switch (conStr.getType()) {
                        case SINGLE_CONNECTION:
                            return ConnectionImpl.getInstance(conStr.getMainHost());
                        case FAILOVER_CONNECTION:
                        case FAILOVER_DNS_SRV_CONNECTION:
                            return FailoverConnectionProxy.createProxyInstance(conStr);
                        case LOADBALANCE_CONNECTION:
                        case LOADBALANCE_DNS_SRV_CONNECTION:
                            return LoadBalancedConnectionProxy.createProxyInstance(conStr);
                        case REPLICATION_CONNECTION:
                        case REPLICATION_DNS_SRV_CONNECTION:
                            return ReplicationConnectionProxy.createProxyInstance(conStr);
                        default:
                            return null;
                    }
                }
            } catch (UnsupportedConnectionStringException var5) {
                return null;
            } catch (CJException var6) {
                throw (UnableToConnectException)ExceptionFactory.createException(UnableToConnectException.class, Messages.getString("NonRegisteringDriver.17", new Object[]{var6.toString()}), var6);
            }
        } catch (CJException var7) {
            throw SQLExceptionsMapping.translateException(var7);
        }
    }

这是个 SINGLE_CONNECTION ,所以调用的就是 return ConnectionImpl.getInstance(conStr.getMainHost());
然后在这里设置了代理类

1
2
3
4
5
6
7
8
9
public PooledConnection(Connection connection, PooledDataSource dataSource) {
    this.hashCode = connection.hashCode();
    this.realConnection = connection;
    this.dataSource = dataSource;
    this.createdTimestamp = System.currentTimeMillis();
    this.lastUsedTimestamp = System.currentTimeMillis();
    this.valid = true;
    this.proxyConnection = (Connection) Proxy.newProxyInstance(Connection.class.getClassLoader(), IFACES, this);
  }

结合这个

1
2
3
4
@Override
public Connection getConnection() throws SQLException {
  return popConnection(dataSource.getUsername(), dataSource.getPassword()).getProxyConnection();
}

所以最终的connection就是com.mysql.cj.jdbc.ConnectionImpl@358ab600

0%
