@Override protectedvoiddoRun() { /* * Do not cache and re-use the value of socketWrapper.getSocket() in * this method. If the socket closes the value will be updated to * CLOSED_NIO_CHANNEL and the previous value potentially re-used for * a new connection. That can result in a stale cached value which * in turn can result in unintentionally closing currently active * connections. */ Pollerpoller= NioEndpoint.this.poller; if (poller == null) { socketWrapper.close();
protectedvoiddoRun() { /* * Do not cache and re-use the value of socketWrapper.getSocket() in * this method. If the socket closes the value will be updated to * CLOSED_NIO_CHANNEL and the previous value potentially re-used for * a new connection. That can result in a stale cached value which * in turn can result in unintentionally closing currently active * connections. */ Pollerpoller= NioEndpoint.this.poller; if (poller == null) { socketWrapper.close(); return; }
try { inthandshake= -1; try { if (socketWrapper.getSocket().isHandshakeComplete()) { // No TLS handshaking required. Let the handler // process this socket / event combination. handshake = 0; } elseif (event == SocketEvent.STOP || event == SocketEvent.DISCONNECT || event == SocketEvent.ERROR) { // Unable to complete the TLS handshake. Treat it as // if the handshake failed. handshake = -1; } else { handshake = socketWrapper.getSocket().handshake(event == SocketEvent.OPEN_READ, event == SocketEvent.OPEN_WRITE); // The handshake process reads/writes from/to the // socket. status may therefore be OPEN_WRITE once // the handshake completes. However, the handshake // happens when the socket is opened so the status // must always be OPEN_READ after it completes. It // is OK to always set this as it is only used if // the handshake completes. event = SocketEvent.OPEN_READ; } } catch (IOException x) { handshake = -1; if (log.isDebugEnabled()) { log.debug("Error during SSL handshake",x); } } catch (CancelledKeyException ckx) { handshake = -1; } if (handshake == 0) { SocketStatestate= SocketState.OPEN; // Process the request from this socket if (event == null) { state = getHandler().process(socketWrapper, SocketEvent.OPEN_READ); } else { state = getHandler().process(socketWrapper, event); } if (state == SocketState.CLOSED) { poller.cancelledKey(getSelectionKey(), socketWrapper); }
可以看到,先 new 了 StandardServer,再 new 了 StandardService,可以理解为创建 Server 后具体是由 service 进行服务, 而在 service 中就是上面的配置文件里显示的,service 包含了 connector,可以是多个connector,负责接入,具体内容可以参看上一篇 而后是 Engine,Engine 的关系是一个 Service 有一个 Engine,Engine 负责处理真正的逻辑,
// Make sure parseBodyMethodsSet has a default if (null == parseBodyMethodsSet) { setParseBodyMethods(getParseBodyMethods()); }
if (protocolHandler.isAprRequired() && !AprStatus.isInstanceCreated()) { thrownewLifecycleException(sm.getString("coyoteConnector.protocolHandlerNoAprListener", getProtocolHandlerClassName())); } if (protocolHandler.isAprRequired() && !AprStatus.isAprAvailable()) { thrownewLifecycleException(sm.getString("coyoteConnector.protocolHandlerNoAprLibrary", getProtocolHandlerClassName())); } if (AprStatus.isAprAvailable() && AprStatus.getUseOpenSSL() && protocolHandler instanceof AbstractHttp11JsseProtocol) { AbstractHttp11JsseProtocol<?> jsseProtocolHandler = (AbstractHttp11JsseProtocol<?>) protocolHandler; if (jsseProtocolHandler.isSSLEnabled() && jsseProtocolHandler.getSslImplementationName() == null) { // OpenSSL is compatible with the JSSE configuration, so use it if APR is available jsseProtocolHandler.setSslImplementationName(OpenSSLImplementation.class.getName()); } }
try { // Loop until we receive a shutdown command while (!stopCalled) {
// Loop if endpoint is paused while (endpoint.isPaused() && !stopCalled) { state = AcceptorState.PAUSED; try { Thread.sleep(50); } catch (InterruptedException e) { // Ignore } }
if (stopCalled) { break; } state = AcceptorState.RUNNING;
try { //if we have reached max connections, wait endpoint.countUpOrAwaitConnection();
// Endpoint might have been paused while waiting for latch // If that is the case, don't accept new connections if (endpoint.isPaused()) { continue; }
Usocket=null; try { // Accept the next incoming connection from the server // socket socket = endpoint.serverSocketAccept(); } catch (Exception ioe) { // We didn't get a socket endpoint.countDownConnection(); if (endpoint.isRunning()) { // Introduce delay if necessary errorDelay = handleExceptionWithDelay(errorDelay); // re-throw throw ioe; } else { break; } } // Successful accept, reset the error delay errorDelay = 0;
// Configure the socket if (!stopCalled && !endpoint.isPaused()) { // setSocketOptions() will hand the socket off to // an appropriate processor if successful if (!endpoint.setSocketOptions(socket)) { endpoint.closeSocket(socket); } } else { endpoint.destroySocket(socket); } } catch (Throwable t) { ExceptionUtils.handleThrowable(t); Stringmsg= sm.getString("endpoint.accept.fail"); // APR specific. // Could push this down but not sure it is worth the trouble. if (t instanceof Error) { Errore= (Error) t; if (e.getError() == 233) { // Not an error on HP-UX so log as a warning // so it can be filtered out on that platform // See bug 50273 log.warn(msg, t); } else { log.error(msg, t); } } else { log.error(msg, t); } } } } finally { stopLatch.countDown(); } state = AcceptorState.ENDED; }
// Set socket properties // Disable blocking, polling will be used socket.configureBlocking(false); if (getUnixDomainSocketPath() == null) { socketProperties.setProperties(socket.socket()); }
socketWrapper.setReadTimeout(getConnectionTimeout()); socketWrapper.setWriteTimeout(getConnectionTimeout()); socketWrapper.setKeepAliveLeft(NioEndpoint.this.getMaxKeepAliveRequests()); poller.register(socketWrapper); returntrue; } catch (Throwable t) { ExceptionUtils.handleThrowable(t); try { log.error(sm.getString("endpoint.socketOptionsError"), t); } catch (Throwable tt) { ExceptionUtils.handleThrowable(tt); } if (socketWrapper == null) { destroySocket(socket); } } // Tell to close the socket if needed returnfalse; }
@Override publicvoidrun() { // Loop until destroy() is called while (true) {
booleanhasEvents=false;
try { if (!close) { hasEvents = events(); if (wakeupCounter.getAndSet(-1) > 0) { // If we are here, means we have other stuff to do // Do a non blocking select keyCount = selector.selectNow(); } else { keyCount = selector.select(selectorTimeout); } wakeupCounter.set(0); } if (close) { events(); timeout(0, false); try { selector.close(); } catch (IOException ioe) { log.error(sm.getString("endpoint.nio.selectorCloseFail"), ioe); } break; } // Either we timed out or we woke up, process events first if (keyCount == 0) { hasEvents = (hasEvents | events()); } } catch (Throwable x) { ExceptionUtils.handleThrowable(x); log.error(sm.getString("endpoint.nio.selectorLoopError"), x); continue; }
Iterator<SelectionKey> iterator = keyCount > 0 ? selector.selectedKeys().iterator() : null; // Walk through the collection of ready keys and dispatch // any active event. while (iterator != null && iterator.hasNext()) { SelectionKeysk= iterator.next(); iterator.remove(); NioSocketWrappersocketWrapper= (NioSocketWrapper) sk.attachment(); // Attachment may be null if another thread has called // cancelledKey() if (socketWrapper != null) { processKey(sk, socketWrapper); } }
// Process timeouts timeout(keyCount,hasEvents); }
// 去获取处理器 // Determine handler for the current request. mappedHandler = getHandler(processedRequest); if (mappedHandler == null) { noHandlerFound(processedRequest, response); return; }
// Determine handler adapter for the current request. HandlerAdapterha= getHandlerAdapter(mappedHandler.getHandler());
// Process last-modified header, if supported by the handler. Stringmethod= request.getMethod(); booleanisGet= HttpMethod.GET.matches(method); if (isGet || HttpMethod.HEAD.matches(method)) { longlastModified= ha.getLastModified(request, mappedHandler.getHandler()); if (newServletWebRequest(request, response).checkNotModified(lastModified) && isGet) { return; } }
if (!mappedHandler.applyPreHandle(processedRequest, response)) { return; }
// Actually invoke the handler. mv = ha.handle(processedRequest, response, mappedHandler.getHandler());
protected HandlerAdapter getHandlerAdapter(Object handler)throws ServletException { if (this.handlerAdapters != null) { for (HandlerAdapter adapter : this.handlerAdapters) { if (adapter.supports(handler)) { return adapter; } } } thrownewServletException("No adapter for handler [" + handler + "]: The DispatcherServlet configuration needs to include a HandlerAdapter that supports this handler"); }
